Step 13: Gable Vent Assembly
Part 3
Components
1 x Continous Hinge (short)
Hardware
12 x #8 x 1/2” Pan Screw
S5
Wood Parts
1 x (2282) Gable End Vent
Continuous Hinge (short)
S5
x 12
(2282)
F13.9
F13.10
Outside View
Continuous Hinge
Notch on inside
bottom
Side View
S5
x 12
(2282)
