Step 17: Install Access Window
Part 1
F17.1
Continuous
Hinge (long)
(2271)
Hardware
18 x #8 x 1/2” Pan Screw
S5
S5
Wood Parts
1 x (2271) Access Window
Components
1 x Continuous Hinge (long)
x 18
Hinge centered on
Access Window
Notch on inside
bottom
Continuous
Hinge (long)
Side View
F17.2
