Yardline 4130 User Manual

29
A - FRAME INSTALL
Two people are needed
to raise and steady
Swing Beam and A-Frame.
3-3/4” Hex Bolt
Flat Washer
x1
2098-H
Flat Washer
Lock Nut
x4
x4
NOTE: Ensure two to three threads
are exposed past Lock Nut.
A - FRAME
INSTALL
Pre-drill four 3/16” pilot holes, 2” DEEP.
Drill-holes must be 3/16”
IMPORTANT!
