31
SWING
SWING BEAM
x1
2106-H
Position swing beam assembly resting upon tent frame upper rail.
Ensure swing beam assembly is centered at vertical tent support and mark Bent Plate holes.
CENTER
RIGHT SIDE
SWING BEAM
SWING SWING BEAM
Pre-drill four 1/4" pilot holes
at marked locations.
Re-drill all four holes from opposite side
using 1/2" bit.
Pre-drill four 3/16” pilot holes into Swing Beam
at marked locations 2” DEEP.
SEE PAGE 7
