43
This space intentionally left blank.
METAL HANDRAIL
METAL HANDRAIL
INSTALL
INSTALL
Flat Washer
Flat Washer
Lock Washer
2” Button Head Screw
Acorn Nut
Lock Nut
x1
2309
Remove 1-1/4 Hex Bolt, T-Nut and washers
from location (left of rockwall).
