59
5/4 x 4 x 37”
x1
2374-MS
CANOPY
CANOPY
INSTALL
INSTALL
5/4 x 4 x 22-1/2”
x2
2375-MS
3” Screw
FLUSH
FLUSH
FLUSH
x4
Pre-Drill 1/8” hole x2
3” Screw
3” Screw
x6
FLUSH
