SOLID ROOF INSTALL
(40) 1-1/4”
Wood Screws
5/8 x 3-1/4 x 47”
x5
2338-MS
5/8 x 3-1/4 x 47”
x5
2338-MS
Flush
WARNING! Install screws  ush with
roof board
Install 5 roof slats on both sides of roof.
SOLID ROOF INSTALL
(8) 1-1/4”
Wood Screws
5/8 x 3-1/4 x 47”
x2
2338-MS
Center roof panels on rafters.
Ensure equal 2” overhang on both sides.
Flush
41-1/8"
Maintain 41-1/8" dimension
between rafters.
2"
2"
