23
PARTS REQUIRED:
FRONT GABLE WALL
Center OY on top plate ush to edge of panel .
Secure with (5) 3" screws spaced evenly and screwed-in at an angle.
5
3" (7,6 cm)
x5
Screws
Front wall
panel
OY
OY
Flush to
Flush
Front Wall
Panel
UM
OY
Top Plate
x1
OY
2 x 3 x 72" (5,1 x 7,6 x 182,9 cm)
FINISH
Your front gable wall is now assembled.
Carefully ip the gable wall over.
CENTER CENTER
