Yardline RIDGEPOINTE - LOFT SUPPORTS

30
INSIDE OF SHED
PARTS REQUIRED:
LOFT SUPPORTS
Center TP on back wall top plate, ush to outside of panels .
Working inside, secure TP with (5) 3" screws as shown.
2
1
BEGIN
TP
CENTER
CENTER
Flush to
outside

Flush
x5
3" (7,6 cm)
x1
TP
2 x 4 x 96" (5,1 x 10,2 x 243,8 cm)

Screws
Flush to

Flush
Back wall
panel
TP

