Yardline RIDGEPOINTE - Page 53

51
LOFT
6th
4th
Flush Flush
PARTS REQUIRED:
COLLAR TIES
FINISH
2
1
BEGIN
Position and level TM on 4th and 6th rafters from back wall. Flush TM to roof panels.
HI NT: For best appearance install TM on rafter facing away from door.
Secure with 3" nails, as shown.
Your collar ties are now installed.

Nails

Nails
3" (7,6 cm)
x12
TM
TM
x2
2 x 4 x 72" (5,1 x 10,2 x 182,9 cm)
