PARTS REQUIRED:
GABLE WINDOW
Secure window trim with (10) 2" nishing nails into gable panel.
Center window trim on window.
3
x2
19/32 x 3-1/2 x 18-1/2" (1,5 x 8,9 x 47 cm)
TNE
x2
19/32 x 3-1/2 x 11-1/2" (1,5 x 8,9 x 29,2 cm)
UAF
2" (5,1 cm)
x10
TNE
TNE
UAF UAF
CENTER
TRIM
ON WINDOW
Avoid nailing
into metal
window ange
Flush
Flush
