CATEGORY PART DESCRIPTION PART SIZE PART ITEM # BUILDING QTY. PART ID
Ladder Block 2 X 3 X 5-1/2" Q 05080000000 6
URB
Over Door Nailer LUM SPF 2 X 3 X 72 #2&BTR Q 72000000000 1
OY
Back Horizontal Gable Connector 2 X 3 X 10 5/8" 51.5* B/E Q 10105151000 1
UVE
Front Horizontal Gable Connector 2 X 3 X 20 1/2" 51.5* B/E Q 20085151000 1
WAF
Shelf Support 2 X 3 X 10 1/8" SUPPORT Q 10020000000 12
AE
Overhang Rafter 2 X 3 X 83-13/16" L/S 38.5* OVERHANG RAFTER Q 83133939000 4
HPP
Rafter 2 X 4 X 83-13/16" @ 38.5* B/E BIRDSMOUTH RAFTER O 8313393900N 12
GPN
Loft Supports "A"/Top & Bottom Plate 2 X 4 X 94 1/2" DOUBLER O 94080000000 6
UN
Loft Supports "C" LUM SPF 2X4X96 #2&BTR 12306 1
TP
Loft Supports "B" 2 X 4 X 24" DOUBLER / PLATE O 24000000000 2
RL
Back Wall Top & Bottom Plate "A" LUM SPF 2X4X92-5/8 #2&BTR 12305 2
TJ
Back Wall Top & Bottom Plate "B" 2 X 4 X 20 3/8" DOUBLER O 20060000000 2
JBD
SW Top / Bottom Plate 2 X 4 X 46-1/2" PLATE O 46080000000 4
OP
Wall Studs 2 X 4 X 68" STUD O 68000000000 24
UM
Back Wall Gable Connector 2 X 4 X 34" @ 38.5* GABLE CONNECTOR O 34003900000 2
FOB
Front Gable Connector 2 X 4 X 40-15/16" @ 38.5* GABLE CONNECTOR O 40153900000 2
EHV
Front Wall Bottom Plate 2 X 4 X 28 1/2" PLATE O 28080000000 2
QR
Collar Tie *LUM SPF 2X4X72 #2&BTR O 72000000000 2
TM
Front Wall Top Plate "A" 2 X 4 X 85-1/4" PLATE O 85040000000 1
CYA
Front Wall Top Plate "B" 2 X 4 X 27-3/4" PLATE O 27120000000 1
BXC
Soffit Corner Block "A" 2 X 6 X 3-5/8" SOFFIT BLOCK N 03100000000 2
LUA
Soffit Corner Block "B" 2 X 6 X 5-1/4" SOFFIT BLOCK N 05040000000 2
AYB
Floor Bond "B" LUM TRTD 2 X 4 X 48 #2&BTR P 48000000000 4
---
Floor Joist "A" LUM TRTD 2 X 4 X 93 #2&BTR P 93000000000 9
---
Floor Bond "A" LUM TRTD 2 X 4 X 72 #2&BTR P 72000000000 4 ---
Floor Joist "B"
2 X 4 X 42 TREATED P 42000000000 9
---
1 X 3 PINE
Gauge Block 1 X 3 X 5" PINE FILLER U 05000000000 1
GAA
Shelf Fascia "A" LUM SPF 1X4X96 SQ EDGE PET 14407 2
KP
Shelf Fascia "B"
1 X 4 X 23 7/8" PINE FASCIA T 23140000000 2
JS
Large Upper Roof Panel OSB 7/16" x 4' x 8' 11110 2
---
Small Upper Roof Panel 7/16" OSB 23 1/4" X 48" ROOF C 48002304000 2
---
Large Lower Roof Panel 7/16" OSB 36-5/16" X 96" ROOF PANEL C 96003605000 2
---
Over Hang Roof Panel "A" 7/16" OSB 31 3/4" X 48" ROOF C 48003112000 2
---
Small Lower Roof Panel 7/16" OSB 23-1/4" X 36-5/16" C 36052304000 2
---
Over Hang Roof Panel "B" 7/16" OSB 31-3/4" X 36-5/16" C 36053112000 2
---
Loft Panel 7/16" OSB 23 7/8" X 96" ROOF C 96002314000 1
---
Shelf Brackets EZ 8" 8" X 12 1/2" PRECUT for J 120808000PP 12
---
Shelf Panel "B" 7/16" OSB 11 1/2" X 23 7/8" C 23141108000 2
---
Shelf Panel "A" 7/16" OSB 11 1/2" X 96" ROOF C 96001108000 2
---
Floor Panel 'A' OSB 5/8" X 4' X 8' 11117 2
---
Floor Panel "B" 5/8" OSB 45" X 96" FLOOR PANEL E 96004500000 1
---
Floor Panel "C" 5/8" OSB 23 7/8" X 96" FLOOR E 96002314000 1
---
Floor Panel "D" 5/8" OSB 23-7/8" X 45" E 45002314000 1
---
Soffit Support "A" 5/8" OSB 1 1/2" X 96" E 96000108000 2
---
Soffit Support "B" 5/8" OSB 1 1/2" X 46 3/4" E 46120108000 2
---
GUSSETS
Gusset EZ 8" 7-1/4 x 18-1/4" GUSSET J 18040704400 11
---
Front Wall Panel 3/8" NG 19-7/8" X 72" K 72001914000 2
---
Front Wing Panel 3/8" NG 11 7/8" X 72" K 72001114000 2
---
Side Wall "A" / Back Wall Panel SIDING NGSE 3/8X4'X6' 11509 4
---
Side Wall Panel "B" 3/8" NG 46 1/8"x 72" PANEL K 72004602000 4
---
Side Wall Panel "C" 3/8"NG 23 7/8" X72"PANEL OR K 72002314000 1
---
Front Gable Soffit 3/8" NG 8 1/2" X 76-5/8" SOFFIT K 76100808000 2
---
Corner Soffit 3/8" NG X 4-1/8" X 8-1/2" K 08080402000 2
---
Side Wall Soffit "A" 3/8" NG 5-3/16" X 79-3/4" K 79120503000 2
---
Side Wall Soffit "B" 3/8" NG 5-3/16" X 71 1/4" K 71040503000 2
---
Corner Trim Side 3/8" NG 1 3/4" X 67-9/16" K 67090112000 4
---
Soffit Corner Spacer 3/8" NG X 2" X 5" K 05000200440 2
---
Gable Filler 3/8" NG 7 1/4" X 18 1/4" GABLE K 18040704000 2
---
Front Gable Panel RIGHT 3/8" NG 41-5/16" X 48" RIGHT K 48004105300 1
---
Front Gable Panel LEFT 3/8" NG 41-5/16" X 48" LEFT K 48004105400 1
---
Back Gable Panel RIGHT 3/8" NG 42-1/2" X 48" RIGHT K 48004208344 1
---
Back Gable Panel LEFT 3/8" NG 42-1/2" X 48" LEFT K 48004208444 1
---
Eave Fascia "A" 3/8" NG 3-1/8" X 71 1/4" K 71040302000 2
---
Eave Fascia "B" 3/8" NG 3-1/8" X 79-3/4" K 79120302000 2
---
Corner Trim Front/Back 3/8" NG 1 3/4" X 70 1/2" K 70080112000 4
---
Gable Decoration 3/8" NG 14 5/8" X 43 1/8" GABLE DECORATION K 4302141000G 1
---
Back Center Gable Panel 3/8" NG 23-7/8" X 44 13/16" CENTER GABLE K 44132314000 1
---
Front Center Gable Panel w/ Hole 3/8" NG 23-7/8" X 43 9/16" CENTER GABLE w/ HOLE K 4309231400W 1
---
Horizontal Middle Door Rail 19/32 TST 2 1/2" X 20-5/8" UT20100208000 2
GPA
Right Crossbuck 19/32 TST 2 1/2" X 49-3/16" @ 21.5* L/S RGT UT49030208121 1
HNR
Left Crossbuck 19/32 TST 2 1/2" X 49-3/16" @ 21.5* L/S LFT UT49030208221 1
HNL
Gable Cleat 19/32 TST 2 1/2" X 23" RAIL UT23000208000 2
GI
Right Decorative Gable Trim 19/32 TST 2 1/2" X 27-9/16" @ 38.5* O/E RGT TRIM UT27090208152 1
BZR
Left Decorative Gable Trim 19/32 TST 2 1/2" X 27-9/16" @ 38.5* O/E LFT TRIM UT27090208252 1
BZL
Gable Trim RIGHT 19/32 TST 3 1/2" X 81-1/4" @ 38.5* B/E RIGHT TRIM UT81040308139 2
AOR
Gable Trim LEFT 19/32 TST 3 1/2" X 81-1/4" @ 38.5* B/E LEFT TRIM UT81040308239 2
AOL
Gable Window Trim / Horizontal 19/32 TST 3 1/2" X 18" TRIM UT18080308000 2
TNE
Gable Window Trim / Vertical 19/32 TST 3 1/2" X 11-1/2" UT11080308000 2
UAF
Over Door Trim 19/32 TST 3 1/2" X 65-1/4" UT65040308000 1
LHC
Corner Soffit Cap RIGHT 19/32" X 5-1/2" X 6-5/8" Right Gable Cap UT06100508100 2
---
Corner Soffit Cap LEFT 19/32" X 5-1/2" X 6-5/8" Left Gable Cap UT06100508200 2
---
Door Stiffener LSL 1-1/4 X 2-1/4 X 69 PET 12715 2
OO
Transom Window - Door WINDOW 16-3/4X21-3/4 TRANSOM 15284 2
---
Black T-Handle HANDLE - T 5-1/2" SHAFT & "D" 15375 1
---
Faux Hinges HINGE (FAUX) w/ SCREWS (4 HING 15246 1
---
Threshold THRESHOLD 7/8" X 1-1/2" X 55-7/8 15419 1
---
Hardware Kit H/K RIDGEPOINTE 8 X 12 15948 1
---
Gable Window WINDOW 12" SQUARE 15273 1
---
2" 6d Nails NAIL 6D 2" BOX HDG BOX 15105 6
---
3" 10d Nails NAIL 10D 3" BOX HDG BOX 15109 3
---
VENT EXTERIOR-WHITE VENT 16" X 8" EXTERIOR (WHITE) 15002 2
---
PACKAGING
Instructions 16191 1
---
30163-L LEFT DOOR ASSEMBLY
Left Door Panel *3/8" NG 27-3/8" X 71-1/2" LEFT DOOR PANEL K 710827062AW 1 ---
Left Hinge Assembly
*HINGE PREM.(LT) 19/32 X4 (GREEN 30133-ATT 1 ---
Vertical Door Stiles 19/32 TST 4" X 71 5/8" STILE UT71100308000 1 ZK
Horizontal Lower Door Rail 19/32 TST 3 1/2" X 20-5/8" UT20100308000 2 GEC
30163-R RIGHT DOOR ASSEMBLY
Right Door Panel *3/8" NG 27-3/8" X 71-1/2" RIGHT DOOR PANEL K 710827061AW 1 ---
Right Hinge Assembly *HINGE PREM.(RT) 19/32 X4 (RED 30122-ATT 1 ---
Vertical Door Stiles 19/32 TST 4" X 71 5/8" STILE UT71100308000 1 ZK
Horizontal Lower Door Rail 19/32 TST 3 1/2" X 21" UT21000308000 2 QK
PURCHASED COMPONENTS
Left Door Assembly
Right Door Assembly
7/16 OSB
5/8 OSB
NO GROOVE SIDING
19/32 X 3 SMART TRIM
19/32 X 4 SMART TRIM
19/32 X 6 SMART TRIM
2 X 3
2 X 4
2 X 6
2 X 4 TREATED FLOOR FRAME
1 X 4 PINE
16191 10' x 12' Order Form
