Yardmaster 1010 TYZ - Page 4

201.3
x6
1520mm
502.2
x4
1834mm
506.3
x4
230mm
203.29
x2
1520mm
503.02
X3
615mm
507
x2
160mm
204.29
x2
1520mm
503.07
x1
490mm
508
x2
45mm
301
x2
920mm
503.08
x1
690mm
509
x2
45mm
302
x2
920mm
504.00
x2
94mm
603.18
x4
1395mm
305.3
x2
995mm
504.10
x2
1144mm
603.63
x2
1390mm
501.14
x2
1234mm
504.17
x2
1744mm
615.02
x1
1264mm
501.2
x2
1834mm
505
x2
145mm
6071
x4
30mm
502.14
x4
1234mm
506
x2
145mm
401.14
x3
1233mm
407EA
x2
69mm
401.20
x3
1833mm
408409.3EA
x2
934mm
406
x4
86mm
608.3EA
x1
1226mm
407
x2
150mm
3
