THROTTLE STOP SCREW
Your engine is not factory-equipped with a spark arrester. In
some areas, it is illegal to operate an engine without a spark
arrester. Check local laws and regulations. A spark arrester is
available from authorized servicing dealers.
The spark arrester must be serviced every 100 hours to keep it
functioning as designed.
If the engine has been running, the mufer will be very hot. Allow
the mufer to cool before servicing the spark arrester.
SPARK ARRESTER SERVICE (optional equipment)
Remove the three 4 mm screws from the exhaust deector,
and remove the deector.
Remove the four 5 mm screws from the muffler protector
and remove the mufer protector.
Remove the 4 mm screw from the spark arrester, and
remove the spark arrester from the mufer.
Use a brush to remove carbon deposits from the spark
arrester screen. Be careful to avoid damaging the screen.
The spark arrester must be free of breaks and holes. Replace
the spark arrester if it is damaged.
Install the spark arrester, muffler protector, and exhaust
deector in the reverse order of disassembly.
1.
2.
3.
4.
5.
SCREEN
5mm SCREWS
M
UFFLER
PROTECTOR
MUFFLER
8mm NUTS
GASKET
4mm SCREW
S
PARK
ARRESTER
Never use an engine without an appropriate spark
arrester in the forest areas! Doing so may cause a re!
13
|
Maintenance
