YARDMAX YB6270 User Manual

PLASTIC SKID SHOES (OPTIONAL)
Optional reversible poly skid shoes protect decorative
surface.
To do so:
Loose the two nuts which secure the chute bracket
and reposition it slightly.
Retighten the nuts.
1.
2.
10 mm
13 mm
18 mm
16 mm
30 mm
32 mm
X 2
Figure 11
Figure 12
Figure 13b
Figure 13a
DRIFT CUTTERS (OPTIONAL)
Drift cutters break up snow drifts that are taller than
the auger housing and direct the snow into the auger.
Store the drift cutters on the auger housing when not
in use. Reposition drift cutters so they face forward as
shown. Wing nuts should be fastened on the outside
of the auger housing.
16
Two-Stage Snow Blower
»
Operator’s Manual
Adjustment
|
30255JUS25M100.indd 16 2016/9/2 14:49:34
