Two-Stage Snow Blower
»
Operator’s Manual
PARTS LIST
|
No. Description
Qty
109 Driven Pulley Bracket 1
110 Friction Wheel Retaining Spring 1
111 Flange Lock Nut M16x1.5 1
112
Locating Knot
2
113 Locating Shaft 1
114 Flange Lock Nut M10 1
115 Engine Belt Cover 1
116 Driven Pulley Hub 1
117 Ball Bearing 6006-2RS 1
118 Engine Pulley 1
119 Drive Belt 1
120 Key 6X6X45 1
121 Spring Washer 10 1
122 Washer 1
123 Belt Pulley 1
124 Drive Clutch Idler 1
125 Bushing 1
126 Bolt 5/16-24unf 1
127 Drive Clutch Idler Bracket 1
128 FT Bolt M8x30 1
129
Spacer
1
130 Engine 1
No. Description
Qty
131 Bolt 5/16-24unf 2
132 Belt Blocker 1
133 Extension Spring 1
134 Jam Nut 5/16-24unf 1
135 FT Bolt M8x35 4
136 Flat Washer 10 6
137 Flange Lock Nut M8 4
138 Spring Clip 1
139 Shift Rod 1
140 Operating Handle 1
141 Handle 2
142 Flange Lock Nut M10 2
143 Screw M10x55 2
144 Chute Adjustable Cable 1
145 Rail Handle 1
146 Handle Base 2
147 Handle Locate Jacket 2
148 Screw M6x60 2
149 Screw M6x40 4
150 Control Panel 1
151 Arc Washer 8 2
152 Arc Washer 10 2
No. Description
Qty
153 FT Bolt M10x40 2
154 FT Bolt M10x20 2
155 Directional Chute Control Lever Knob 1
156 Circlip 10 1
157 Directional Chute Control Lever 1
158 Chute Bracket 1
159 Rubber Spacer 1
160 Washer 10 1
No. Description
Qty
1* Handle Knob Assembly 4
2* Bolt M8x25 4
3* Drift Cutter 2
No. Description
Qty
4* Plastic Skid Shoe 2
OPTIONAL DRIFT CUTTERS
OPTIONAL SKID SHOES
