Yardworks 060-1721-4 User Manual

model no. 060-1721-4 | contact us: 1.866.523.5218
5
Parts List
Item Description Drawing Qty
1 Motor cover 341011166 1
2 Screw M5x15 3220435 1
3 12 A Motor 3610138-1 1
4 Lock nut M6 3220537 1
5 Bolt M6x12 3220137 1
6 Motor spindle sleeve 3320238A 1
7 Resistance and bracket 36901227-1 1
8 Lock nut M5 3220439 1
9 Screw M5x10 3220575 1
10 Fan 3410237 1
11 Resistance block
3410290-1 1
12 Screw M5x20 3220850 1
13
7” Wheel cover
34203229-13 1
14
7” Wheel (right)
34203229-4 1
15 Knob 3410835-4 1
16 Height adjustment plate (right) 3330837-1 1
17 Side discharge door 3410537 1
18 Spring 3340237-1 1
19 Side discharge deector 3410637 1
20 Side discharge pin 3320338A 1
21 Side discharge bracket
3330437-1 1
22 Bolt M6x8
3220136 1
23
18” Deck
31301221-3 1
24 Cotter
3290135 1
25
18” Front wheel axle
3110137-2 1
26 Blade
33303463 1
27 Blade insulator
3410535 1
28 Spacer
3331435A 1
29 Blade nut
3221037A 1
30 Wheel ferrule
3320237 1
31 Clip
32905302A 1
32 Link bar
3330537-2 1
33 Extension spring
3340137-1 1
34 Bolt M10x20
3221637 1
35 Height adjustment plate (left)
3330737-1 1
36 Rear wheel axle
3110237-2 1

Yardworks 060-1721-4 Specifications

General

Brand	Yardworks
Model	060-1721-4
Category	Lawn Mower
Language	English
