Yardworks 060-1721-4 User Manual

model no. 060-1721-4 | contact us: 1.866.523.5218
8
INSTALLING THE SIDE DISCHARGE CHUTE
1. Lift the side discharge cover (1).
2. Align the grooves on the deector (2) with the pins on the underside of the cover.
3. Lower the deector until the hooks on the mower deck are secured in the openings in the
deector.
4. Release the deector and cover.
1
2
Assembly

Yardworks 060-1721-4 Specifications

General

Brand	Yardworks
Model	060-1721-4
Category	Lawn Mower
Language	English
