Yardworks 060-2341-2 User Manual

model no. 060-2341-2 | contact us: 1.866.523.5218
12
Operation Instructions
6. ADJUSTING THE HEIGHT (SEE FIG. G)
Rotate the Height adjustment locking mechanism to loose it. Adjust the length of the Aluminum
tube to be more comfortable for you, then rotate the Height adjustment locking mechanism to
the opposite direction to ensure it is xed rmly.
7. ADJUSTING THE DIRECTION OF TRIMMING & EDGING (SEE FIG. H)
Unscrew the Handle rotation locking mechanism, (a) in the direction of unlocking, and turn it in a
counterclockwise direction.
Tighten the Handle rotation locking mechanism (a) in the direction of locking, and turn it in a
clockwise direction.
8. ADJUSTING THE CUTTING ANGLE (SEE FIG. I1,I2)
To adjust the Main handle angle, downwards or convert the tool from trimming mode to edging
mode, put one foot on the motor housing portion of the trimmer head, then grip the main handle
and apply adequate force on the Main handle pushing it downwards.
Adjust the Main handle angle upwards, put one foot on the safety guard area of the trimmer
head, then grip the main handle, apply adequate force to adjust.
a
G
H
I1
I2

Yardworks 060-2341-2 Specifications

General

Brand	Yardworks
Model	060-2341-2
Category	Trimmer
Language	English
