Yardworks CLM48BCU1 User Manual

model no. 060-1982-2 | contact us: 1.866.523.5218 model no. 060-1982-2 | contact us: 1.866.523.5218
13
Product Diagram
1. Upper handle
2. Start bar
3. Self-propel
engagement bar
4. Upper handle lock knob
5. Lower handle
6. Lower handle lock knob
7. Rear discharge guard
8. Cutting height
adjustment lever
9. Battery pack cover
10. Wheel
11. Carry handle
12. Side discharge cover
13. Grass collection bag
14. Lock off button
15. Side discharge chute
(See Fig. E2)
16. Battery pack (See Fig.
G2) (060-1989-8)
17. Battery pack release
button (See Fig. G2)
18. Mulching block (See
Fig. C1)
19. Charger (060-1990-2)
WARNING: Any other accessory or attachment may increase the risk of injury.
1
3
14
13
7
12
2
4
5
6
8
9
11
10
19

Yardworks CLM48BCU1 Specifications

General

Brand	Yardworks
Model	CLM48BCU1
Category	Lawn Mower
Language	English
