YASKAWA 1000 Series Installation Manual

6 Basic Operation
40 YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual
Procedure Example: Setting Parameters
The example below explains how to change the Deceleration Time parameter C1-20 to 20.0
sec from the default setting of 10.0 sec.
6. Press and the option will display Japanese.
Procedure LCD Display
1. DC Bus Voltage Reference display.
2. Press to select the Programming Mode.
3. Press to show the Initialization display.
4. Press to select parameter C1-20
and press .
Procedure LCD Display
䉦䉨䉮䊚㩷䉦䊮䊥䊢䉡
- MODE -
U1-51= 0330V
U1-52= 295V
U1-53= 0.0A
DRV
Volt Ref
Rdy
LSEQ
LREF
HELP
-MODE- PRG
DATA
Programming
←→
-PRMSET-
Initialization
Select Language
PRG
A1-00=0
F1 F2
←→
-PRMSET-
VRef Up Rate 1
PRG
C1-20= 010.0sec
㧔0.0㨪100.0㧕
10.0sec
