6 Basic Operation
YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual 47
Procedure Example: Setting Parameters
The example below explains how to change the Analog Output 1 Monitor Selection
parameter H4-01 to 158 from the default setting of 157.
6. Press and the option will display Japanese.
Procedure LCD Display
1. DC Bus Voltage display.
2. Press to select the Programming Mode.
3. Press to show the Initialization display.
4. Press to select parameter H4-01
and press .
Procedure LCD Display
䉦䉨䉮䊚㩷䉦䊮䊥䊢䉡
- MODE -
U1-51= 0330V
U1-52= 295V
U1-53= 0.0A
DRV
DC V Feedback
Rdy
LSEQ
LREF
HELP
-MODE- PRG
DATA
Programming
←→
-PRMSET-
Initialization
Select Language
PRG
A1-00=0
F1 F2
←→
-PRMSET-
Term FM FunSel
PRG
H4-01= 157
*157*
AC Power
“157”
