Yealink SIP-T46S Quick Installation Guide

www.yealink.com
Copyright 2017 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD.
c
Following the drilling template above, you can mount
the IP phone to the wall, as shown below
(Take a SIP-T46G IP phone as an example):
You can also download the wall mount drilling template
online: http://www.yealink.com/Support.aspx.
For SIP-T29G/T27P/T27G IP phones:
73mm
65mm
130mm
Screw position
Max:4.5mm
(0.177”)
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
x 3
For a SIP-T46S/T46G IP phone:
126.6mm
86.9mm
x 4
Screw position
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
Max:4.5mm
(0.177”)

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
