<4. Measurement Procedures> 4-19
IM 80J01A01-01E
It changes to temperature setting window. Input control temperature to
“Setting” and click “Set”.
Guarranty range of chamber temperature depends on room
temperature (refer to following chart).
For example, to set chamber temperature 37 󳇾, set room temperature
20 󳇾 - 30 󳇾.
10 15
15
20
20 25 30 35
25
30
35
40
45
Room Temperature [󳇾]
Chamber Temperature [󳇾]
Note
If 35 mm dishes is used, input “control temperature – 0.8 󳇾”
(example: If you want to set chamber temperature to 37 󳇾,
input “36.2” to “Setting” )
