Saving and Loading Data
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
SetupItems
• Save>Autosave
Settings Description
On Automatically saves the measured data to the CF card. Specify On to
enable the media FIFO function.
Off Does not automatically save the data. Save the measured data manually
to the CF card or USB flash memory (/USB1 option).
• Save>MediaFIFO(ReleaseNumber2orLater)
This item appears if Auto save is set to On.
Settings Description
On Enable media FIFO. Constantly retains the most recent data files in the
CF card.
Off Disable media FIFO. Replace the CF card if the free space on the CF
card drops low.
• Fileheader>Characters
Set the header comment to be written to the data file. (Up to 50 characters,
A a # 1
)
• Datafilename>Structure
Sets the structure of the file name when saving data.
Settings Description
Date Serial number + user-assigned character string + date
Serial Serial number + user-assigned character string
Batch Serial number + batch name (when using the batch function)
• Datafilename>Identifiedstrings
Set the user-assigned section of the file name. (Up to 16 characters,
A a # 1
)
Symbols that can be used: #, %, (, ), +, -, ., @, °, and _.
For details on the data file name, see section 1.4.
• Savedirectory>Directoryname
Set the name of the directory on the storage medium for saving the data on the
external storage medium. (Up to 20 characters,
A a # 1
)
Symbols that can be used: #, %, (, ), +, -, ., @, °, and _.
Strings that cannot be used: AUX, CON, PRN, NUL, CLOCK, COM1 to COM9, and
LPT1 to LPT9.
6.2SettingtheMethodforSavingtheData
