6-8
IM 04L42B01-01E
• DisplayingtheTextFieldSettings
If you are using the multi batch function (/BT2 option), see the DX1000/DX1000N/
DX2000 Multi Batch (/BT2) User’s Manual, IM04L41B01-03E.
1.
In the operation mode, press FUNC.
The FUNC key menu appears.
2.
Press the Textfield soft key.
The text field settings are displayed.
Page switch mark
(release numbers 3
and later)
Eight text fields are
displayed on a single page.
Use the
left and right arrow
keys to switch the page.
The text field contents are displayed on page 3. Use the leftandrightarrowkeys to
switch pages (release number 3 or later).
• StartingRecording(Memorystart)
1.
Press START to open the start recording screen (release number 3 or later).
* On DXs with the /AS1 advanced security option, recording will not start, even if you press
START in setting mode.
2.
Enter the batch number, lot number, and comments.
To edit the contents of a text field, proceed to step 3.
3.
Select Input, and press DISP/ENTER. The text field screen appears (release
numbers 4 and later).
6.3UsingtheBatchFunction
