13-14
IM 04L42B01-01E
3LegIsolatedRTDInput(/N2)
Item Specifications
Input terminal All the RTD input terminals (A, B, and b) are isolated on each channel.
Applies to DX2010, DX2020, DX2030, DX2040, and DX2048
Note: On the DX2004 and DX2008 standard models, all the terminals (A, B, and b) are already
isolated on each channel.
ExtendedInputType(/N3)
Item Specifications
Measurement/display accuracy
Under standard operating conditions
Kp vs Au7Fe 0.0 to 300.0K
PLATINEL 0.0 to 1400.0°C
PR40-20 0.0 to 1900.0°C
NiNiMo 0.0 to 1310.0°C
W/WRe26 0.0 to 2400.0°C
Type N(AWG14) 0.0 to 1300.0°C
XK GOST
*
2
–200.0 to 600.0
Pt50 –200.0 to 550.0°C
Ni100(SAMA) –200.0 to 250.0°C
Ni100(DIN) –60.0 to 180.0°C
Ni120 –70.0 to 200.0°C
J263*B 0.0 to 300.0K
Cu53 –50.0 to 150.0°C
Cu100 –50.0 to 150.0°C
Pt25 –200.0 to 550.0°C
Pt100GOST
*
2
–200.0 to 600.0°C
Cu100 GOST
*
2
–200.0 to 200.0°C
Cu50 GOST
*
2
–200.0 to 200.0°C
Cu10 GOST
*
2
–200.0 to 200.0°C
Pt46 GOST
*
2
–200.0 to 550.0°C
*1 Measuring current i = 1 mA
*2 Available for release numbers 3 and later.
*3 Available for release numbers 4 and later. Double the resistance of a 100 ohm Platinum (TCR = .003902 ohms/ohm/°C)
Curve A resistor made by Weed Instrument.
Measurement
Range
Measurement Accuracy
Max.
Resolution
Input Type
Thermocouple
RTD
*
1
0 to 20 K Within ±4.5 K
20 to 300 K Within ±2.5 K
±(0.25% of rdg + 2.3°C)
0 to 450°C Accuracy not guaranteed
450 to 750°C ±(0.9% of rdg + 3.2°C)
750 to 1100°C ±(0.9% of rdg + 1.3°C)
1100 to 1900°C ±(0.9% of rdg + 0.4°C)
±(0.25% of rdg + 0.7°C)
0 to 400°C ±15.0°C
400 to 2400°C ±(0.2% of rdg + 2.0°C)
±(0.2% of rdg + 1.3°C)
–200 to –100°C ±(0.25% of rdg +1.0°C)
–100 to 600°C ±(0.25% of rdg + 0.8°C)
±(0.3% of rdg + 0.6°C)
±(0.15% of rdg + 0.4°C)
±(0.15% of rdg + 0.4°C)
±(0.15% of rdg + 0.4°C)
0 to 40 K Within ±3.0 K
40 to 300 K Within ±1.0 K
±(0.15% of rdg + 0.8°C)
±(0.2% of rdg + 1.0°C)
±(0.15% of rdg + 0.6°C)
±(0.15% of rdg + 0.3°C)
±(0.15% of rdg + 0.3°C)
±(0.4% of rdg + 0.5°C)
±(1.5% of rdg + 3.0°C)
±(0.3% of rdg + 0.8°C)
Within ±13.5 K
Within ±7.5 K
±(0.25% of rdg + 8.0°C)
Accuracy not guaranteed
±(0.9% of rdg + 15.0°C)
±(0.9% of rdg + 6.0°C)
±(0.9% of rdg + 3.0°C)
±(0.5% of rdg + 3.5°C)
±30.0°C
±(0.4% of rdg + 4.0°C)
±(0.5% of rdg + 7.0°C)
±(0.5%of rdg +5.0°C)
±(0.5%of rdg +4.0°C)
±(0.6% of rdg + 3.0°C)
±(0.3% of rdg + 2.0°C)
±(0.3% of rdg + 2.0°C)
±(0.3% of rdg + 2.0°C)
Within ±9.0 K
Within ±3.0 K
±(0.3% of rdg + 4.0°C)
±(0.4% of rdg + 5.0°C)
±(0.3% of rdg + 3.0°C)
±(0.3% of rdg + 1.5°C)
±(0.3% of rdg + 1.5°C)
±(0.8% of rdg + 2.5°C)
±(3.0% of rdg + 15.0°C)
±(0.6% of rdg + 4.0°C)
0.1K
0.1°C
0.1K
0.1°C
A/D integration time: 16.7 ms or more
A/D integration time:
1.67 ms
Pt200 (WEED)
*3
–100.0 to 450.0°C ±(0.3% of rdg + 0.6°C)
±(0.6% of rdg + 3.0°C)
Input source resistance
Thermocouple input:
2kΩorless
RTDinput:1Ωorlessperwire(Theresistanceofallthreewiresmustbeequal).
Ambient temperature influence (applies when the A/D integration time is 16.67 ms or greater, with temperature variation of 10°C)
TC input ±(0.1%ofrdg+0.05%ofrange)orless,excludingtheerrorofreferencejunctioncompensation
RTD input ±(0.2% of range + 2 digits) or less
Input source resistance
TC input
Withvariationof+1kΩ:
±10 µV or less
RTD input Withvariationof1Ωperwire(resistanceofallthreewiresmustbeequal):
±(0.1% of rdg + 1 digit) or less
Withmaximumdifferenceof100mΩbetweenwires:Approx.1°C
