Appendix3 TextFileDataFormat
This section explains the format of text files. The text files that the DX can create are
manual sampled data files and report files.
In the explanation below, CRLF represents a terminator.
FormatoftheManualSampleDataFile
• Themanual sampled data is output using numerical values and strings in text format
delimited by tabs.
• ValuesofmeasurementchannelssettoSkip and computation and external input
channels set to Off are not output.
• Thedataisappendedtothefileeachtimemanualsampleoperationisperformed.
Format
YRECCRLF
Manual Sample Data Version 1.02.00 CRLF
Model DX2000 CRLF
Language Code shift-JIS CRLF
File Status ffffffff CRLF
Serial No. III•••I CRLF
File Header HHH•••H CRLF
Ch ccccc ccccc ••• ccccc CRLF
Ch Id ddd•••d ddd•••d ••• ddd•••d CRLF
Tag ttt•••t ttt•••t ••• ttt•••t CRLF
Unit uuuuuu uuuuuu ••• uuuuuu CRLF
yyyy/mo/dd hh:mi:ss nnn•••n nnn•••n ••• nnn•••n CRLF
* Ch Id is only output when Tag numbers are being used, on DXs with release number 3 or
later.
ffffffff
File status (8 characters)
Complete
Completed. (A file with 100 manually sampled
data acquisitions that is now complete.)
Progress
Data is being added. (An incomplete file that
does not yet have 100 manually sampled data
acquisitions.)
Decrease
The file is defective. (A file that is missing some
of the manually sampled data that was stored
on it.)
III•••I
Serial number of the DX (16 characters)
HHH•••H
File header (50 characters)
ccccc
Channel number (5 characters)
ddd···d
Tag number (16 characters)
ttt•••t
Tag comment (32 characters)
uuuuuu
Unit (6 characters)
yyyy/mo/dd hh:mi:ss
Sampling year, month, day, and time (19 characters)
nnn•••n
Measured value (13 characters)
