YOKOGAWA GX60 User Manual

13
All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L52B01-01EN
December. 11, 2015-00
• Numberofdisplaygroups:
 GP10:6max.perbatch
 Numberofchannelspergroup:10
 GP20-1:6max.perbatch
 Numberofchannelspergroup:20
 GP20-2:12max.perbatch
 Numberofchannelspergroup:20
 Channelsassignedtothedisplaygroupofeach
batch and those set as recording channels are
recordedtodatales.
• Batchsinglesettings:Group,tripline,leheader,
datalename,texteld,batchnumber,lot
number
OPC-UASERVER(/E3)
DataacquiredbytheGPcanbeaccessedthrough
Ethernetcommunicationfromahostsystem
(OPC-UAclient).
• Communication
 Mode:OPC-UAServer
 Encoding:UABinary
 Protocol:OPCUATCP
 Maximumnumberofconnections:3sessions
 Prole MicroEmbeddedDeviceServer
• Security
Type: None
Encryption: None
 Login:Anonymous,Username
• Dataacquisition:Measurementchannel,
computationchannel,communicationchannel
valueandalarmstatus
• Datawriting:Measurementchannel(DOchannel
only),communicationchannel
• Otheracquiredinformation:Devicename,serial
number,time,devicestatus
• Portnumber:4840(changeable:1to65535)
• Numberofitems:
 GP10:100max.(MonitoredItem/Session)
 GP20:300max.(MonitoredItem/Session)
• Fastestperiod:100ms
• Serviceset:
Discovery FindServers, GetEndpoints
SecureChannel OpenSecureChannel,
CloseSecureChannel
Session CreateSession,ActivateSession,
CloseSession
View Browse,BrowseNext,
TranslateBrowsePathsToNodeIds
Attribute Read,Write
MonitoredItem CreateMonitoredItems,
ModifyMonitoredItems,
DeleteMonitoredItems,
SetMonitoringMode
Subscription CreateSubscription,
ModifySubscription,
DeleteSubscriptions,Publish,
Republish,
SetPublishingMode
SLMPCOMMUNICATION(MitsubishiPLC)(/E4)
Protocolfunctionthatenablesconnectionfrom
a GP to Mitsubishi Electric PLCs without
sequencerprograms.
•
Numberofconnectiondestinationservers:16max.
• Readcycle:100ms/200ms/500ms/1s/2s/5s/10s/2
0s/30s/1min
• Communicableinternaldata:
 Specialrelay(SM),specialregister(SD),input
(X),output(Y),internalrelay(M),latchrelay(L),
annunciator(F),edgerelay(V),linkrelay(B),
dataregister(D),linkregister(W),timercontact
(TS),timercoil(TC),currenttimervalue(TN),
integrationtimercontact(SS),integrationtimer
coil(SC),currentintegrationtimervalue(SN),
counter contact (CS), counter coil (CC), current
counter value (CN), special link relay (SB),
speciallinkregister(SW),directaccessinput
(DX),directaccessoutput(DY),indexregister
(Z),leregister(R,ZR),extendeddataregister
(D),extendedlinkregister(W)
Devicecodeisindicatedinparentheses.
