YOKOGAWA ScopeCorder DL850E User Manual

19-6
IM DL850E-01EN
Saving Setup Data (Setup)
You can save the DL850E/DL850EV setup information to the specified storage medium. The extension is .SET.
Save Destination (File List), File Name (File Name), Comment (Comment)
Saving to Internal Memory
You can save setup data to internal memory from the Store/Recall menu.
Saving Other Types of Data (Others)
You can save the following types of data.
Save Destination (File List), File Name (File Name), Comment (Comment)
Data Type (Data Type)
• Screen capture (Screen Image): You can save the displayed screen image to a file in PNG, BMP, or JPEG
format. You can also save the screen image from the menu that appears when you press the PRINT MENU key.
•
Snaps
hot waveforms (Snap): You can save the waveform data captured in a snapshot. The extension is .SNP.
• Measure (Measure): You can save the results of the automated measurement of waveform parameters to a
file in CSV format.
•
FFT analysis results (FFT): You can save FFT analysis results to a file in CSV format.
Automated Measurement V
alues of Waveform Parameters (Measure)
Save the results of automatic waveform parameter measurement to a file in CSV format. The extension is .CSV.
CSV files are text files that contain data separated by commas. They are used to convert data between
spreadsheet and database applications.
The maximum number of previous values that you can save is equal to 100000 ÷ number of items that are
turned on.
Data size in bytes = Number of measured items × 15 × number of history waveforms
Save Conditions (Measure Save Setup)
•
Unit (Unit)
You can select whether to save the units of measure along with the measured results.
• ON: Units are saved.
• OFF: Units are not saved.
•
Time information (Time Info.)
FFT Analysis Results (FFT)
You can save the analysis results of FFT1 or FFT2 to a file in CSV format. The extension is .CSV.
Save Conditions (FFT Save Setup)
• Frequency Information (Frequency Info.)
You can select whether to save frequency information along with computed results.
• ON: Frequency information is saved.
• OFF: Frequency information is not saved.
• Decimal Point (Decimal Point)
Saving (Execute Save)
Saves the data to the specified save destination with the specified file name.
19 Saving and Loading Data
