Yokomo YD-2 AC User Manual

Productspecificationsandpricesaresubjecttochangewithoutnotice.
PARTS LIST
YD-2E SERIES
ItemNo. ItemName Quantity Price

YD-2E
PLUS
Kits
DP-YD2E DriftPackageYD-2E ¥19,800
DP-YD2EG DriftPackageYD-2EG ¥23,500
DP-YD2EPLS
DriftPackageYD-2EPlusKit
(MattGraphiteSpecifications)
¥38,800
Conversions
Y2-GC1 GradeUpConversion1forYD2 ¥7,800 ★★
Y2-GC2 GradeUpConversion2forYD2 ¥6,980 ★★
RearAarmSuspensionKit
Y2-RAC3 TopShaftofY2-RACforYD-2/EX/PLS 1 ¥1,380 ★★
Y2-RAC4 SpurGearHubofY2-RACforYD-2/EX/PLS 1 ¥1,300 ★★
Y2-RAC5 UpperAarmPinofY2-RACforYD-2/EX/PLS ¥300 ★★
Y2-RAC6 RearSusMountofY2-RACforYD-2/EX/PLS 1 ¥1,680 ★★
Y2-RAC7 ShockendBallofY2-RACforYD-2/EX/PLS ¥200 ★★
Y2-RAC8 RShockTowerofY2-RACforYD-2/EX/PLS ¥5,800 ★★
SteeringGyro
YG-302 SteeringGyroforUsewith3chRadio ¥4,300 ※★
DPP-302V4 STGyro[Black]w/EPAdj.forUsew/2-3ch ¥6,480 ★ ★
ChassisParts
Y2-001B Alum.FrontBumperBraceforYD2/YD4 1 ¥2,800 ★ ★
Y4-001 FrontPlasticBumperforYD2/YD4 ¥400
●●
Y4-001F FoamFrontBumperforYD2/YD4 1 ¥480 ● ●
SD-BW BumperWeight,10g
5 ¥780 ★★
Y2-001R Wide/NarrowDiffuserforDP-YD2 ¥1,200 ● ●
Y2-001RA Wide/NarrowDiffuserforYD-2series ¥1,200 ★ ★
Y4-001R Wide/NarrowDiffuserforDP-YD4 ¥1,200 ★ ★
SD-001R RearBumper
1 ¥250 ★ ★
Y2-002MG MatGraphiteMainChassisforYD2/EX/PLS 1 ¥10,800 ★ ●
Y2-002 MainChassis(Mold)forDP-YD2 1 ¥3,500 ● ★
ZC-002P ChassisProtectiveSheetw/YokomoLogo 1 ¥980
★★
Y2-003MG MatGraphiteUpperDeckforYD-2/PLS 1 ¥2,160 ★ ●
Y2-003 UpperDeck(Mold)forDP-YD2 1 ¥850 ● ★
Y2-302A ChamferedFrontBulkHeadAforYD-2 ¥5,300 ★ ★
Y2-302B ChamferedFrontBulkHeadBforYD-2 ¥4,500 ★ ★
Y2-302AM ChamferedUpperArmHolderforYD-2
1 ¥1,800 ★ ★
Y2-302AB FrontBulkHeadBraceforYD-2/EX1/PLS 1 ¥980 ★ ★
Y2-302MR FrontBulkHead/UpperArmHolderforYD2 ¥750
●●
Y2-303AR ChamferedRearBraceSupportforYD-2 1 ¥2,200 ★ ★
Y2-303RB ChamferedRearBracew/oFanforYD-2 1 ¥2,500 ★ ★
Y2-303RBF ChamferedRearBracew/FanforYD-2 1 ¥3,900 ★ ★
Y2-303MR UpperDeckMount/RBraceSupportforYD2 ¥650 ● ●
Y4-016 Front/RearBodyMountforYD2/YD4 ¥540 ● ●
D-176 BlackMultiBodyMountforDrift
2 ¥680 ★ ★
Y2-301 SusMount/Hub/ServoMountetc.forYD2 ¥1,100 ● ●
RC-313S SmallsizeHoodPin(12pcs.) 12 ¥120 ● ●
RC-313SB SmallsizeHoodPinBlack(10pcs.) 10 ¥200 ★★
Y2-TSS 3mmTitaniumScrewSetforYD-2/Plus ¥3,400 ★ ★
GearDiff.
Y2-500GS PlasticGearDiff.Assy.forYD-2/YZ-2 1 ¥3,600 ● ●
Y2-500GSA MoldGearDiff.Assy.w/Alum.DcupforYD-2 1 ¥3,980 ★ ★
B8-500DP DriveCupProtecterforAlum.DriveCup ¥360 ★ ★
Y2-501GS2 DriveCupofGearDiff/SolidAxle/forYD-2
2 ¥1,050 ● ●
Y2-501GSA AlumOutDriveCupofGearDiffforYD-2 2 ¥1,200 ★ ★
Y2-501GG GasketofGearDiff.forYD-2/YZ-2 1 ¥200 ● ●
Y2-503GH GearDiff.Case/CapforYD-2/YZ-2 ¥700 ● ●
Y2-503GP PlasticBevelGearsetforYD2/EX1/PLS ¥600 ● ●
BD-500GA Alm.GearDiffshaftforBD7/5B-MAX2/4
2 ¥580 ★ ★
CS-SLG SealGreasefor"O"ring/Gasket ¥860 ★★
SolidAxle
Y2-502 SolidAxleSetforYD-2 1 ¥3,000 ★ ★
B8-500DP DriveCupProtecterforAlum.DriveCup ¥360 ★ ★
Y2-501GS2 DriveCupofGearDiff/SolidAxle/forYD-2
2 ¥1,050 ● ●
Y2-501GSA AlumOutDriveCupofGearDiffforYD-2 2 ¥1,200 ★ ★
Y2-501GG GasketofGearDiff.forYD-2/YZ-2 1 ¥200 ● ●
Y2-503GH GearDiff.Case/CapforYD-2/YZ-2 ¥700 ● ●
BallDiff.
Y2-500 BallDiff.KitforYD-2 ¥2,800 ★ ★
B2-501MR L/RDiffOutdriveHubforB-MAX2MR/RS ¥1,300 ★ ★
Z2-503 48p52TBallDiff.GearforYZ-2CA/DT/4 1 ¥400 ★ ★
ZD-505 3/32PrecisionBalls 24 ¥150 ★ ★
Z2-505T 3/32TungstenCarbideBall(14pcs.) 14 ¥1,120 ★ ★
B2-506 Diff.DriveRing 2 ¥400 ★ ★
ZS-507 DiffThrustWashers/DiffThrustBalls ¥200 ★ ★
ZC-507T 1/16TungstenCarbideBall(16pcs.) ¥680 ★ ★
BM-508 Diff.AdjustableKit ¥280
★★
B2-508TS Locking Ｔ nut/ThurstSpg.forYZ-2/4/MAX2 ¥700 ★ ★
BB-85-4 φ 5 ｘφ 8x2.5mmBallBearing(4pcs.) 4 ¥980 ★ ★
BB-850P φ 5X φ 8x2.5mmSuperPrec.Bearing(2pcs) 2 ¥980 ★ ★
BB-850CB φ 5x φ 8x2.5mmCeramicBallbearing(2pcs)
2 ¥720 ★ ★
CS-DG Diff.GreaseforDiff.Ball ¥1,000 ★ ★
CS-HDL Diff.GreaseHardtype ¥480 ★ ★
DriveTrain
Y2-302 TrasmissionCaseforDP-YD2 ¥850 ●●
Y2-303I IdlerShaftforYD-2 1 ¥200 ●●
Y2-303IA Alum.IdlerShaftforYD-2 1 ¥300 ★★
Y2-303IG GraphiteIdlerShaftforYD-2 2 ¥750 ★★
Y2-304 MotorMountforDP-YD2 1 ¥1,500 ●●
Y2-304H SpecialMotorMountforDP-YD2 1 ¥2,300 ★★
Y2-503I IdlerGearforYD-2 1 ¥420 ●●
Y2-503IA Alm.IdlerGearforYD-2 1 ¥680 ★★
Y4-630 Alum.SpurGearHubforYD-2/YD4 1 ¥1,200 ●●
Y4-630C ChamferedSpurGearHubforDP-YD4 1 ¥1,950 ★★
Y2-631 Alum.TopShaftw/48P20TGearforDP-YD2 1 ¥1,380 ●●
UniversalShaft&Axle
Y2-010FA Alum.FrontAxleforDP-YD2 2 ¥800 ★★
Y2-010F FrontAxleforDP-YD2 2 ¥500 ●●
Y2-010FB LowFrictionFr.AxleBBφ 5X φ 10(4pcs) 4 ¥1,080 ★★
Y2-010 RearUniv.DriveShaft(49mm)forDP-YD2 2 ¥2,100 ●●
Y4-010 UniversalDriveShaft(47mm)forDP-YD4 2 ¥2,100 ★★
Y4-010A UniversalAxleforDP-YD2/YD4 1 ¥500 ● ●
Y4-010490 49mmUniversalBoneforYD2/YD4 1 ¥600 ● ●
Y4-010B UniversalBoneforDP-YD4 1 ¥600 ★★
BD-010440 44.0mmUniversalBoneforBD7/BD5 1 ¥520 ★★
BD-01440B Alum.44.0mmUniversalBoneforBD-7 1 ¥900 ★★
D-153B51 51.0mmBoneforNarrowSTblock 1 ¥520 ★★
D-153B53 53.0mmBoneforNarrowSTblock 1 ¥520 ★★
B8-500DP DriveCupProtecterforAlum.DriveCup ¥360 ★★
Y4-010TP
Univ.CupJointforYD2/YD4
(Joint/φ 2pin/SetScrew)
1each ¥250 ●●
WheelHub
Y2-301 SusMount/Hub/ServoMountetc.forYD2 ¥1,100 ●●
SD-011 WheelHubPin&Nut(4pcseach) 4 ¥200 ●●
SD-011DC2 ChromePlatedWheelHub/LicensePlate ¥720 ★★
SD-011DC3 WheelDiscHubsforA-arm ¥600 ★★
Y2-011CB5 5.0mmClampingWheelHubforYD-2 2 ¥1,000 ★★
Y2-011CB6 6.0mmClampingWheelHubforYD-2 2 ¥1,000 ★★
Y2-011CB7 7.0mmClampingWheelHubforYD-2 2 ¥1,000 ★★
Y2-011CB8 8.0mmClampingWheelHubforYD-2 2 ¥1,000 ★★
ZS-011EL Alum.EasyWheelHubforMR-4series 2 ¥780 ★★
ZR-011SM RebuildKitforEZWheelHub 4 ¥150 ★★
B7-011NB 4.5mmClampWheelHubforBD716 2 ¥1,180 ★★
ZS-011TSB BlackTreadAdjustSpacer0.5mm/1.0mm 4set ¥420 ★★
ZS-011CM RebuildKitforCrampingWheelHub ¥150 ★★
ZS-011NM RebuildKitfor4.5mmCrampingWheelHub ¥240 ★★
ZC-N4FBK M4Alum.FlangeSerrationNutBlack 4 ¥380 ★★
ZC-N4FBL M4Alum.FlangeSerrationNutBlue 4 ¥380 ★★
PinionandSpurgear
BM-4820 HARDSTEELPINIONGEARDP48-20T 1 ¥420 ●●
SG-A4884 Precision48PitchSpurGear84T 1
¥550 ●●
Steeringlinkage
ZC-204517 Alum.17mmClampServoHorn(25TSpline) ¥1,380 ★ ★
ZC-204520 Alum.20mmClampServoHorn(25TSpline) ¥1,380 ★ ★
ZC-204523 Alum.23mmClampServoHorn(25TSpline) ¥1,480 ★ ★
ZC-204317 Alum.26mmClampServoHorn(23TSpline) ¥1,380 ★ ★
ZC-204320 Alum.29mmClampServoHorn(23TSpline) ¥1,380 ★★
ZC-204323 Alum.32mmClampServoHorn(23TSpline) ¥1,480 ★★
Y4-201P Alum.BellcrankPostforDP-YD4
1 ¥200 ● ●
