York AFFINITY DEZ048 - Page 28

294604-YTG-G-0511
28 Johnson Controls Unitary Products
115°F 125°F
1000
77 35.0 3.3 22.0 15.3 10.9 - - - 32.1 3.6 23.7 15.7 10.7 - - -
72 31.1 3.3 24.6 20.3 16.0 11.8 - - 27.5 3.5 23.3 19.2 15.0 10.9 - -
67 27.2 3.2 27.2 25.3 21.2 16.9 12.7 - 22.9 3.4 22.9 22.8 19.4 15.3 11.2 -
62 25.7 3.1 25.7 25.7 24.0 19.7 15.4 11.2 22.6 3.3 22.6 22.6 21.5 17.3 13.2 9.1
57 25.0 3.1 25.0 25.0 23.3 19.0 14.8 10.5 23.3 3.3 23.3 23.3 22.0 17.8 13.7 9.6
1100
77 35.3 3.3 24.5 16.2 11.4 - - - 32.3 3.6 26.4 17.4 11.1 - - -
72 31.4 3.3 26.0 21.4 16.8 12.2 - - 27.7 3.5 24.7 20.2 15.6 11.1 - -
67 27.4 3.2 27.4 26.5 22.2 17.6 13.0 - 23.1 3.4 23.1 23.1 20.2 15.6 11.1 -
62 26.0 3.1 26.0 26.0 25.1 20.5 15.9 11.3 22.8 3.3 22.8 22.8 22.3 17.8 13.2 8.7
57 25.2 3.1 25.2 25.2 24.4 19.8 15.2 10.6 23.5 3.3 23.5 23.5 22.8 18.3 13.7 9.2
1200
77 35.7 3.4 27.0 17.2 11.9 - - - 32.6 3.6 29.1 19.2 11.5 - - -
72 31.7 3.3 27.4 22.5 17.6 12.7 - - 27.9 3.5 26.2 21.2 16.3 11.3 - -
67 27.7 3.2 27.7 27.7 23.2 18.3 13.4 - 23.3 3.4 23.3 23.3 21.0 16.0 11.0 -
62 26.2 3.1 26.2 26.2 26.2 21.3 16.4 11.5 23.0 3.4 23.0 23.0 23.0 18.2 13.2 8.3
57 25.5 3.1 25.5 25.5 25.5 20.6 15.7 10.8 23.7 3.4 23.7 23.7 23.7 18.8 13.8 8.8
1300
72 32.1 3.3 29.6 24.4 19.1 13.8 - - 28.4 3.6 28.4 23.7 18.4 13.0 - -
67 28.1 3.2 28.1 28.1 25.2 19.9 14.7 - 23.7 3.4 23.7 23.7 23.7 18.4 13.1 -
62 26.6 3.2 26.6 26.6 26.6 21.3 16.0 10.7 23.4 3.4 23.4 23.4 23.4 18.0 12.7 7.4
57 25.8 3.2 25.8 25.8 25.8 20.6 15.3 10.0 24.1 3.4 24.1 24.1 24.1 18.8 13.4 8.1
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
DEQ036 (3.0 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
