York Champion Series - Cooling Capacities - BHA048

10 Unitary Products Group
036-21311-003-A-0104
COOLING CAPACITIES - 4 TON (BHA048)
Temperature of Air on
Outdoor Coil
Air On Indoor Coil
1200 CFM 1400 CFM 1600 CFM 1800 CFM 2000 CFM
WB°FWB°FWB°FWB°FWB°F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
53.1 48.6 44.5 43.1 54.8 50.1 45.9 44.5 56.4 51.6 47.4 45.9 57.7 52.8 48.4 46.9 58.9 53.9 49.4 47.8
Total Power
Input KW
4.76 4.68 4.55 4.56 4.89 4.81 4.67 4.69 5.03 4.94 4.80 4.82 5.12 5.03 4.89 4.91 5.21 5.13 4.98 5.00
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 31.3 38.8 44.5 43.1 34.7 42.8 45.9 44.5 38.1 46.8 47.4 45.9 41.5 50.3 48.4 46.9 44.9 53.9 49.4 47.8
83 27.9 35.4 41.7 41.9 30.7 38.8 44.5 43.9 33.4 42.2 47.4 45.9 36.2 45.6 48.4 46.9 39.0 49.1 49.4 47.8
80 24.5 32.0 38.3 38.5 26.6 34.7 41.6 41.8 28.7 37.5 44.9 45.2 30.9 40.3 47.1 46.5 33.0 43.1 49.4 47.8
77 21.1 28.5 34.8 35.1 22.6 30.7 37.5 37.8 24.1 32.8 40.2 40.5 25.6 35.0 41.8 41.2 27.1 37.1 43.4 41.9
74 17.6 25.1 31.4 31.7 18.5 26.6 33.5 33.8 19.4 28.2 35.6 35.9 20.2 29.7 36.5 35.9 21.1 31.2 37.5 35.9
71 - 21.7 28.0 28.2 - 22.6 29.4 29.7 - 23.5 30.9 31.2 - 24.4 31.2 30.6 - 25.2 31.5 30.0
68 - 18.3 24.6 24.8 - 18.6 25.4 25.7 - 18.8 26.2 26.5 - 19.0 25.9 25.3 - 19.2 25.5 24.0
95 °F
Net Cap
MBH
49.6 45.3 41.4 40.0 51.4 47.0 42.9 41.4 53.3 48.7 44.4 42.9 54.5 49.8 45.5 43.9 55.8 51.0 46.6 45.0
Total Power
Input KW
5.12 4.98 4.90 4.88 5.27 5.12 5.04 5.03 5.42 5.27 5.19 5.18 5.53 5.38 5.30 5.28 5.64 5.49 5.40 5.39
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 29.4 36.9 41.4 40.0 32.8 41.1 42.9 41.4 36.3 45.3 44.4 42.9 39.7 48.2 45.5 43.9 43.1 51.0 46.6 45.0
83 25.9 33.5 38.8 38.8 28.8 37.1 41.6 40.8 31.6 40.6 44.4 42.9 34.4 44.1 45.5 43.9 37.1 47.6 46.6 45.0
80 22.5 30.1 35.3 35.3 24.7 33.0 38.8 38.8 26.9 36.0 42.3 42.3 29.1 38.8 44.4 43.6 31.2 41.6 46.6 45.0
77 19.1 26.6 31.9 31.9 20.7 29.0 34.8 34.8 22.3 31.3 37.6 37.6 23.8 33.5 39.1 38.3 25.2 35.7 40.6 39.0
74 15.7 23.2 28.5 28.5 16.6 24.9 30.7 30.7 17.6 26.6 33.0 33.0 18.4 28.2 33.8 33.0 19.3 29.7 34.6 33.0
71 - 19.8 25.1 25.1 - 20.9 26.7 26.7 - 22.0 28.3 28.3 - 22.9 28.5 27.7 - 23.7 28.7 27.1
68 - 16.4 21.7 21.7 - 16.8 22.6 22.7 - 17.3 23.6 23.6 - 17.5 23.2 22.4 - 17.8 22.7 21.1
105 °F
Net Cap
MBH
46.0 41.9 38.8 36.8 47.5 43.3 40.0 38.0 49.0 44.6 41.3 39.2 50.0 45.6 42.1 40.0 51.0 46.5 43.0 40.9
Total Power
Input KW
5.60 5.43 5.32 5.27 5.76 5.58 5.47 5.42 5.91 5.74 5.62 5.56 6.02 5.84 5.73 5.67 6.13 5.95 5.83 5.77
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 28.3 35.7 38.8 36.8 31.6 39.3 40.0 38.0 34.9 43.0 41.3 39.2 38.2 44.7 42.1 40.0 41.4 46.5 43.0 40.9
83 24.8 32.3 36.9 36.0 27.5 35.7 39.1 37.6 30.2 39.1 41.3 39.2 32.8 42.0 42.1 40.0 35.4 44.8 43.0 40.9
80 21.4 28.9 33.4 32.6 23.5 31.7 36.7 35.8 25.6 34.5 39.9 38.9 27.5 37.1 41.5 39.9 29.5 39.7 43.0 40.9
77 18.0 25.4 30.0 29.2 19.5 27.6 32.6 31.7 20.9 29.8 35.3 34.2 22.2 31.8 36.2 34.6 23.5 33.7 37.0 34.9
74 14.6 22.0 26.6 25.7 15.4 23.6 28.6 27.7 16.2 25.1 30.6 29.6 16.9 26.4 30.8 29.3 17.5 27.8 31.1 28.9
71 - 18.6 23.2 22.3 - 19.5 24.6 23.6 - 20.5 25.9 24.9 - 21.1 25.5 23.9 - 21.8 25.1 23.0
68 - 15.2 19.8 18.9 - 15.5 20.5 19.6 - 15.8 21.3 20.3 - 15.8 20.2 18.6 - 15.8 19.2 17.0
115 °F
Net Cap
MBH
42.4 38.5 36.2 33.7 43.6 39.6 37.2 34.6 44.7 40.6 38.1 35.5 45.5 41.3 38.8 36.1 46.3 42.0 39.4 36.7
Total Power
Input KW
6.08 5.89 5.75 5.65 6.24 6.04 5.90 5.80 6.40 6.20 6.05 5.95 6.51 6.30 6.15 6.05 6.62 6.41 6.25 6.15
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 27.2 34.5 36.2 33.7 30.4 37.6 37.2 34.6 33.5 40.6 38.1 35.5 36.6 41.3 38.8 36.1 39.7 42.0 39.4 36.7
83 23.8 31.1 35.0 33.3 26.3 34.4 36.5 34.4 28.9 37.6 38.1 35.5 31.3 39.8 38.8 36.1 33.7 42.0 39.4 36.7
80 20.3 27.7 31.5 29.8 22.3 30.3 34.6 32.7 24.2 32.9 37.6 35.5 26.0 35.4 38.5 36.1 27.8 37.8 39.4 36.7
77 16.9 24.2 28.1 26.4 18.2 26.3 30.5 28.6 19.5 28.3 32.9 30.9 20.7 30.0 33.2 30.8 21.8 31.8 33.5 30.8
74 13.5 20.8 24.7 23.0 14.2 22.2 26.5 24.6 14.9 23.6 28.2 26.2 15.4 24.7 27.9 25.5 15.8 25.9 27.5 24.8
71 - 17.4 21.3 19.6 - 18.2 22.4 20.5 - 19.0 23.6 21.5 - 19.4 22.6 20.2 - 19.9 21.6 18.9
68 - 14.0 17.9 16.1 - 14.1 18.4 16.5 - 14.3 18.9 16.9 - 14.1 17.2 14.9 - 13.9 15.6 12.9
125 °F
Net Cap
MBH
38.9 35.1 33.6 30.6 39.7 35.9 34.3 31.2 40.5 36.6 35.0 31.8 41.0 37.1 35.4 32.2 41.5 37.5 35.9 32.6
Total Power
Input KW
6.6 6.3 6.2 6.0 6.7 6.5 6.3 6.2 6.9 6.7 6.5 6.3 7.0 6.8 6.6 6.4 7.1 6.9 6.7 6.5
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 26.1 33.3 33.6 30.6 29.1 35.8 34.3 31.2 32.2 36.6 35.0 31.8 35.1 37.1 35.4 32.2 38.0 37.5 35.9 32.6
83 22.7 29.9 33.1 30.5 25.1 33.0 34.0 31.2 27.5 36.1 35.0 31.8 29.7 37.1 35.4 32.2 32.0 37.5 35.9 32.6
80 19.2 26.5 29.6 27.1 21.0 29.0 32.4 29.6 22.8 31.4 35.0 31.8 24.4 33.6 35.4 32.2 26.0 35.9 35.9 32.6
77 15.8 23.1 26.2 23.7 17.0 24.9 28.4 25.6 18.2 26.8 30.5 27.5 19.1 28.3 30.2 27.1 20.1 29.9 29.9 26.7
74 12.4 19.6 22.8 20.2 12.9 20.9 24.3 21.5 13.5 22.1 25.9 22.8 13.8 23.0 24.9 21.8 14.1 23.9 24.0 20.7
71 - 16.2 19.4 16.8 - 16.8 20.3 17.5 - 17.4 21.2 18.1 - 17.7 19.6 16.4 - 18.0 18.0 14.7
68 - 12.8 16.0 13.4 - 12.8 16.2 13.4 - 12.8 16.5 13.5 - 12.4 14.3 11.1 - 12.0 12.0 8.8
1
= These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
