York Champion Series - Cooling Capacities - BHA060

Unitary Products Group 11
036-21311-003-A-0104
COOLING CAPACITIES - 5 TON (BHA060)
Temperature of Air on
Outdoor Coil
Air On Indoor Coil
1500 CFM 1750 CFM 2000 CFM 2100 CFM 2200 CFM
WB°FWB°FWB°FWB°FWB°F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
64.1 58.6 52.4 52.6 65.4 59.8 53.5 53.6 66.7 60.9 54.5 54.7 66.0 60.3 54.0 54.1 65.3 59.7 53.4 53.5
Total Power
Input KW
5.52 5.49 5.37 5.44 5.68 5.65 5.52 5.60 5.84 5.81 5.68 5.75 5.95 5.92 5.79 5.87 6.06 6.03 5.90 5.98
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 37.2 47.6 52.4 52.6 41.0 52.3 53.5 53.6 44.9 57.0 54.5 54.7 46.0 58.3 54.0 54.1 47.1 59.5 53.4 53.5
83 32.9 43.4 50.7 41.3 36.0 47.3 52.6 53.0 39.0 51.2 54.5 54.7 39.8 52.1 54.0 54.1 40.5 53.0 53.4 53.5
80 28.6 39.1 46.4 47.1 30.9 42.2 50.1 50.9 33.2 45.4 53.9 54.7 33.6 45.9 53.6 54.1 34.0 46.4 53.4 53.5
77 24.3 34.8 42.1 42.8 25.9 37.2 45.1 45.8 27.4 39.6 48.0 48.8 27.4 39.7 47.4 47.9 27.4 39.8 46.8 47.0
74 20.0 30.5 37.8 38.5 20.8 32.1 40.0 40.8 21.5 33.7 42.2 43.0 21.2 33.5 41.2 41.7 20.8 33.3 40.3 40.4
71 - 26.2 33.6 34.2 - 27.1 35.0 35.7 - 27.9 36.4 37.2 - 27.3 35.0 35.5 - 26.7 33.7 33.8
68 - 22.0 29.3 30.0 - 22.0 29.9 30.6 - 22.1 30.5 31.3 - 21.1 28.8 29.3 - 20.2 27.2 27.3
95 °F
Net Cap
MBH
60.1 54.6 50.2 49.2 61.5 55.8 51.4 50.3 63.0 57.1 52.6 51.5 63.9 58.0 53.4 52.3 64.9 58.9 54.2 53.0
Total Power
Input KW
6.00 5.90 5.81 5.77 6.19 6.09 5.99 5.95 6.37 6.27 6.17 6.12 6.49 6.38 6.28 6.24 6.60 6.50 6.39 6.35
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 35.5 46.0 50.2 49.2 39.5 51.1 51.4 50.3 43.6 56.1 52.6 51.5 45.1 57.5 53.4 52.3 46.6 58.9 54.2 53.0
83 31.2 41.8 48.6 47.7 34.5 46.0 50.6 49.6 37.8 50.3 52.6 51.5 38.9 51.7 53.4 52.3 40.0 53.2 54.2 53.0
80 26.9 37.5 44.3 43.4 29.4 41.0 48.4 47.4 31.9 44.5 52.6 51.5 32.7 45.5 53.4 52.3 33.5 46.6 54.2 53.0
77 22.6 33.2 40.0 39.1 24.4 35.9 43.4 42.4 26.1 38.6 46.7 45.6 26.5 39.3 47.2 46.1 26.9 40.1 47.6 46.5
74 18.4 28.9 35.8 34.8 19.3 30.9 38.3 37.3 20.3 32.8 40.9 39.8 20.3 33.2 41.0 39.9 20.4 33.5 41.1 39.9
71 - 24.6 31.5 30.6 - 25.8 33.3 32.3 - 27.0 35.1 34.0 - 27.0 34.8 33.7 - 27.0 34.5 33.4
68 - 20.4 27.2 26.3 - 20.7 28.2 27.2 - 21.1 29.2 28.2 - 20.8 28.6 27.5 - 20.4 27.9 26.8
105 °F
Net Cap
MBH
56.1 50.2 46.6 45.4 57.5 51.4 47.8 46.5 58.9 52.7 48.9 47.6 59.7 53.4 49.6 48.3 60.5 54.1 50.3 48.9
Total Power
Input KW
6.56 6.43 6.35 6.32 6.75 6.62 6.53 6.51 6.94 6.80 6.71 6.69 7.06 6.92 6.83 6.80 7.18 7.04 6.94 6.92
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 34.5 44.3 46.6 45.4 38.4 48.2 47.8 46.5 42.3 52.2 48.9 47.6 43.7 53.1 49.6 48.3 45.1 54.1 50.3 48.9
83 30.3 40.0 45.7 44.6 33.4 44.1 47.3 46.1 36.5 48.1 48.9 47.6 37.5 49.3 49.6 48.3 38.5 50.6 50.3 48.9
80 26.0 35.8 41.5 40.4 28.3 39.0 45.2 44.0 30.7 42.2 48.9 47.6 31.3 43.1 49.6 48.3 32.0 44.0 50.3 48.9
77 21.7 31.5 37.2 36.1 23.3 33.9 40.1 38.9 24.8 36.4 43.1 41.8 25.1 36.9 43.4 42.1 25.4 37.4 43.7 42.4
74 17.4 27.2 32.9 31.8 18.2 28.9 35.1 33.9 19.0 30.6 37.3 36.0 18.9 30.7 37.2 35.9 18.8 30.9 37.2 35.8
71 - 22.9 28.6 27.5 - 23.8 30.0 28.8 - 24.7 31.5 30.2 - 24.5 31.0 29.7 - 24.3 30.6 29.3
68 - 18.7 24.3 23.2 - 18.8 25.0 23.8 - 18.9 25.6 24.3 - 18.3 24.8 23.5 - 17.8 24.0 22.7
115 °F
Net Cap
MBH
52.0 45.8 43.1 41.6 53.4 47.0 44.2 42.7 54.8 48.2 45.3 43.8 55.4 48.8 45.9 44.3 56.1 49.3 46.4 44.8
Total Power
Input KW
7.13 6.96 6.89 6.88 7.32 7.15 7.07 7.06 7.51 7.34 7.26 7.25 7.64 7.46 7.38 7.37 7.76 7.58 7.50 7.49
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 33.6 42.6 43.1 41.6 37.3 45.4 44.2 42.7 41.1 48.2 45.3 43.8 42.3 48.8 45.9 44.3 43.5 49.3 46.4 44.8
83 29.3 38.3 42.9 41.6 32.3 42.1 44.1 42.7 35.2 45.8 45.3 43.8 36.1 46.9 45.9 44.3 37.0 47.9 46.4 44.8
80 25.0 34.1 38.6 37.3 27.2 37.0 42.0 40.6 29.4 40.0 45.3 43.8 29.9 40.7 45.9 44.3 30.4 41.4 46.4 44.8
77 20.8 29.8 34.3 33.0 22.2 32.0 36.9 35.5 23.6 34.2 39.5 38.0 23.7 34.5 39.7 38.1 23.9 34.8 39.8 38.3
74 16.5 25.5 30.0 28.8 17.1 26.9 31.9 30.5 17.7 28.3 33.7 32.2 17.5 28.3 33.5 31.9 17.3 28.3 33.3 31.7
71 - 21.2 25.8 24.5 - 21.9 26.8 25.4 - 22.5 27.8 26.3 - 22.1 27.3 25.7 - 21.7 26.7 25.2
68 - 16.9 21.5 20.2 - 16.8 21.7 20.3 - 16.7 22.0 20.5 - 15.9 21.1 19.6 - 15.2 20.2 18.6
125 °F
Net Cap
MBH
48.0 41.4 39.5 37.8 49.3 42.6 40.6 38.9 50.7 43.7 41.7 40.0 51.2 44.1 42.1 40.4 51.6 44.5 42.5 40.7
Total Power
Input KW
7.69 7.49 7.42 7.43 7.89 7.68 7.61 7.62 8.08 7.87 7.80 7.81 8.21 8.00 7.92 7.93 8.34 8.12 8.05 8.06
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 32.7 40.9 39.5 37.8 36.2 42.6 40.6 38.9 39.8 43.7 41.7 40.0 40.9 44.1 42.1 40.4 42.0 44.5 42.5 40.7
83 28.4 36.6 39.5 37.8 31.2 40.1 40.6 38.9 34.0 43.6 41.7 40.0 34.7 44.1 42.1 40.4 35.5 44.5 42.5 40.7
80 24.1 32.3 35.7 34.3 26.1 35.1 38.7 37.1 28.2 37.8 41.7 40.0 28.5 38.3 42.1 40.4 28.9 38.8 42.5 40.7
77 19.8 28.1 31.4 30.0 21.1 30.0 33.7 32.1 22.3 31.9 35.9 34.2 22.3 32.1 35.9 34.2 22.3 32.2 35.9 34.2
74 15.5 23.8 27.2 25.7 16.0 25.0 28.6 27.0 16.5 26.1 30.0 28.3 16.1 25.9 29.7 28.0 15.8 25.6 29.4 27.6
71 - 19.5 22.9 21.4 - 19.9 23.6 22.0 - 20.3 24.2 22.5 - 19.7 23.5 21.8 - 19.1 22.8 21.1
68 - 15.2 18.6 17.1 - 14.8 18.5 16.9 - 14.5 18.4 16.7 - 13.5 17.3 15.6 - 12.5 16.3 14.5
1
= These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
