York Champion Series - Cooling Capacities - 1-1;2 Ton (BHA018)

036-21311-003-A-0104
Unitary Products Group 5
COOLING CAPACITIES - 1-1/2 TON (BHA018)
Temperature of Air on
Outdoor Coil
Air On Indoor Coil
450 CFM 525 CFM 600 CFM 675 CFM 750 CFM
WB°FWB°FWB°FWB°FWB°F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
20.5 19.2 16.8 17.4 21.4 19.9 17.5 18.1 22.2 20.7 18.2 18.8 22.6 21.1 18.5 19.1 23.0 21.4 18.8 19.4
Total Power
Input kW
1.84 1.81 1.80 1.79 1.87 1.84 1.83 1.81 1.89 1.87 1.86 1.84 1.92 1.89 1.88 1.86 1.94 1.92 1.90 1.89
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 11.9 14.9 16.8 17.4 13.2 16.6 17.5 18.1 14.6 18.2 18.2 18.8 15.6 19.4 18.5 19.1 16.7 20.7 18.8 19.4
83 10.6 13.6 16.0 16.4 11.7 15.0 17.1 17.6 12.8 16.4 18.2 18.8 13.6 17.4 18.5 19.1 14.4 18.4 18.8 19.4
80 9.3 12.3 14.8 15.1 10.2 13.5 16.2 16.5 11.1 14.7 17.6 18.0 11.6 15.4 18.2 18.7 12.2 16.2 18.8 19.4
77 8.0 11.1 13.5 13.8 8.7 12.0 14.7 15.0 9.3 12.9 15.8 16.2 9.6 13.5 16.2 16.7 10.0 14.0 16.6 17.2
74 6.7 9.8 12.2 12.5 7.1 10.5 13.1 13.5 7.6 11.2 14.1 14.5 7.6 11.5 14.2 14.7 7.7 11.7 14.3 15.0
71 - 8.5 10.9 11.3 - 9.0 11.6 12.0 - 9.4 12.3 12.7 - 9.5 12.2 12.7 - 9.5 12.1 12.7
68 - 7.2 9.6 10.0 - 7.5 10.1 10.5 - 7.7 10.6 11.0 - 7.5 10.2 10.7 - 7.3 9.9 10.5
95 °F
Net Cap
MBH
19.4 17.5 15.0 15.0 20.3 18.3 15.7 15.7 21.2 19.1 16.4 16.4 21.7 19.6 16.8 16.8 22.2 20.1 17.2 17.2
Total Power
Input kW
1.98 1.94 1.90 1.90 2.01 1.97 1.92 1.93 2.03 1.99 1.94 1.95 2.06 2.02 1.97 1.98 2.09 2.04 1.99 2.00
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 11.4 14.2 15.0 15.0 12.8 15.8 15.7 15.7 14.2 17.5 16.4 16.4 15.5 18.8 16.8 16.8 16.7 20.1 17.2 17.2
83 10.1 12.9 14.8 14.8 11.3 14.3 15.6 15.6 12.5 15.8 16.4 16.4 13.5 17.0 16.8 16.8 14.5 18.3 17.2 17.2
80 8.9 11.6 13.6 13.6 9.8 12.8 15.0 15.0 10.7 14.0 16.4 16.4 11.5 15.0 16.8 16.8 12.2 16.0 17.2 17.2
77 7.6 10.3 12.3 12.3 8.3 11.3 13.4 13.5 9.0 12.3 14.6 14.6 9.5 13.0 14.8 14.8 10.0 13.8 14.9 15.0
74 6.3 9.0 11.0 11.0 6.7 9.8 11.9 11.9 7.2 10.5 12.9 12.9 7.5 11.0 12.8 12.8 7.8 11.6 12.7 12.7
71 - 7.7 9.7 9.7 - 8.3 10.4 10.4 - 8.8 11.1 11.1 - 9.0 10.8 10.8 - 9.3 10.5 10.5
68 - 6.5 8.4 8.4 - 6.7 8.9 8.9 - 7.0 9.4 9.4 - 7.0 8.8 8.8 - 7.1 8.2 8.3
105 °F
Net Cap
MBH
18.0 15.9 13.9 13.8 18.7 16.5 14.4 14.3 19.4 17.1 14.9 14.8 19.9 17.5 15.3 15.2 20.4 17.9 15.7 15.6
Total Power
Input KW
2.11 2.04 1.99 2.00 2.14 2.07 2.02 2.03 2.17 2.10 2.05 2.05 2.20 2.13 2.08 2.08 2.23 2.16 2.11 2.12
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 10.9 13.4 13.9 13.8 12.3 14.8 14.4 14.3 13.6 16.3 14.9 14.8 14.9 17.1 15.3 15.2 16.2 17.9 15.7 15.6
83 9.6 12.1 13.6 13.5 10.7 13.5 14.3 14.2 11.9 14.9 14.9 14.8 12.9 16.0 15.3 15.2 13.9 17.0 15.7 15.6
80 8.3 10.9 12.3 12.2 9.2 12.0 13.6 13.5 10.1 13.2 14.9 14.8 10.9 14.2 15.3 15.2 11.7 15.2 15.7 15.6
77 7.0 9.6 11.0 10.9 7.7 10.5 12.1 12.0 8.4 11.4 13.2 13.1 8.9 12.2 13.3 13.2 9.5 13.0 13.4 13.3
74 5.8 8.3 9.7 9.7 6.2 9.0 10.6 10.5 6.6 9.7 11.4 11.3 6.9 10.2 11.3 11.2 7.2 10.8 11.2 11.1
71 - 7.0 8.5 8.4 - 7.5 9.1 9.0 - 7.9 9.7 9.6 - 8.2 9.3 9.2 - 8.5 9.0 8.9
68 - 5.7 7.2 7.1 - 6.0 7.6 7.5 - 6.2 7.9 7.8 - 6.2 7.3 7.2 - 6.3 6.7 6.6
115 °F
Net Cap
MBH
16.6 14.2 12.7 12.5 17.1 14.6 13.1 12.9 17.6 15.0 13.5 13.3 18.1 15.4 13.8 13.6 18.5 15.8 14.2 13.9
Total Power
Input kW
2.23 2.13 2.09 2.09 2.26 2.17 2.13 2.12 2.30 2.20 2.16 2.16 2.34 2.24 2.19 2.19 2.38 2.27 2.23 2.23
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 10.4 12.7 12.7 12.5 11.7 13.9 13.1 12.9 13.0 15.0 13.5 13.3 14.3 15.4 13.8 13.6 15.6 15.8 14.2 13.9
83 9.1 11.4 12.4 12.2 10.2 12.8 12.9 12.7 11.3 14.1 13.5 13.3 12.3 14.9 13.8 13.6 13.4 15.8 14.2 13.9
80 7.8 10.1 11.1 10.9 8.7 11.3 12.3 12.1 9.5 12.4 13.5 13.3 10.3 13.4 13.8 13.6 11.1 14.5 14.2 13.9
77 6.5 8.9 9.8 9.6 7.1 9.7 10.8 10.6 7.8 10.6 11.8 11.5 8.3 11.4 11.8 11.6 8.9 12.2 11.9 11.7
74 5.2 7.6 8.5 8.3 5.6 8.2 9.3 9.1 6.0 8.9 10.0 9.8 6.3 9.4 9.9 9.6 6.7 10.0 9.7 9.5
71 - 6.3 7.2 7.0 - 6.7 7.7 7.5 - 7.1 8.3 8.0 - 7.4 7.9 7.6 - 7.8 7.5 7.2
68 - 5.0 5.9 5.8 - 5.2 6.2 6.0 - 5.4 6.5 6.3 - 5.4 5.9 5.6 - 5.5 5.2 5.0
125 °F
Net Cap
MBH
15.2 12.5 11.6 11.3 15.5 12.7 11.8 11.5 15.8 13.0 12.1 11.7 16.2 13.3 12.4 12.0 16.6 13.6 12.7 12.3
Total Power
Input kW
2.4 2.2 2.2 2.2 2.4 2.3 2.2 2.2 2.4 2.3 2.3 2.3 2.5 2.3 2.3 2.3 2.5 2.4 2.4 2.3
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 9.8 12.0 11.6 11.3 11.1 12.9 11.8 11.5 12.4 13.8 12.1 11.7 13.7 13.7 12.4 12.0 15.0 13.6 12.7 12.3
83 8.6 10.7 11.1 10.8 9.6 12.0 11.6 11.3 10.7 13.3 12.1 11.7 11.7 13.9 12.4 12.0 12.8 14.5 12.7 12.3
80 7.3 9.4 9.8 9.6 8.1 10.5 10.9 10.6 8.9 11.6 12.1 11.7 9.8 12.6 12.4 12.0 10.6 13.7 12.7 12.3
77 6.0 8.1 8.5 8.3 6.6 9.0 9.4 9.1 7.2 9.8 10.3 10.0 7.8 10.6 10.4 10.0 8.3 11.4 10.4 10.1
74 4.7 6.8 7.3 7.0 5.1 7.4 7.9 7.6 5.4 8.1 8.6 8.2 5.8 8.6 8.4 8.0 6.1 9.2 8.2 7.8
71 - 5.6 6.0 5.7 - 5.9 6.4 6.1 - 6.3 6.8 6.5 - 6.6 6.4 6.0 - 7.0 6.0 5.6
68 - 4.3 4.7 4.4 - 4.4 4.9 4.6 - 4.6 5.1 4.7 - 4.6 4.4 4.1 - 4.7 3.7 3.4
1
= These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
