York Champion Series - Cooling Capacities - BHA030

Unitary Products Group 7
036-21311-003-A-0104
COOLING CAPACITIES - 2-1/2 TON (BHA030)
Temperature of Air on
Outdoor Coil
Air On Indoor Coil
750 CFM 875 CFM 1,000 CFM 1,125 CFM 1,250 CFM
WB°FWB°FWB°FWB°FWB°F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
32.5 29.3 26.4 26.0 33.4 30.2 27.1 26.7 34.4 31.1 27.9 27.5 35.7 32.3 29.0 28.6 37.1 33.5 30.1 29.7
Total Power
Input kW
2.94 2.85 2.76 2.74 3.02 2.93 2.84 2.81 3.11 3.02 2.92 2.89 3.15 3.06 2.96 2.93 3.20 3.10 3.01 2.98
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 19.5 23.9 26.4 26.0 21.4 26.2 27.1 26.7 23.4 28.4 27.9 27.5 25.7 31.0 29.0 28.6 28.1 33.5 30.1 29.7
83 17.4 21.8 25.7 26.0 18.9 23.6 26.8 26.7 20.4 25.5 27.9 27.5 22.4 28.0 29.0 28.6 24.4 30.4 30.1 29.7
80 15.2 19.6 23.5 23.9 16.4 21.1 25.3 25.7 17.5 22.6 27.1 27.5 19.1 24.6 28.6 28.6 20.7 26.7 30.1 29.7
77 13.1 17.5 21.4 21.7 13.9 18.6 22.8 23.2 14.6 19.7 24.2 24.6 15.8 21.3 25.3 25.3 16.9 22.9 26.4 26.0
74 10.9 15.4 19.2 19.6 11.3 16.1 20.2 20.6 11.7 16.8 21.2 21.7 12.5 18.0 22.0 22.0 13.2 19.2 22.7 22.2
71 - 13.2 17.1 17.5 - 13.5 17.7 18.1 - 13.9 18.3 18.8 - 14.7 18.6 18.6 - 15.5 19.0 18.5
68 - 11.1 15.0 15.3 - 11.0 15.2 15.6 - 10.9 15.4 15.8 - 11.3 15.3 15.3 - 11.8 15.2 14.8
95 °F
Net Cap
MBH
30.9 27.3 24.3 24.5 31.7 27.9 24.9 25.1 32.4 28.6 25.5 25.7 33.0 29.2 26.0 26.2 33.7 29.7 26.5 26.7
Total Power
Input kW
3.14 3.02 2.92 2.94 3.22 3.09 3.00 3.01 3.29 3.17 3.07 3.09 3.36 3.23 3.13 3.15 3.43 3.30 3.19 3.21
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 18.4 23.0 24.3 24.5 20.3 25.3 24.9 25.1 22.2 27.5 25.5 25.7 24.2 28.6 26.0 26.2 26.2 29.7 26.5 26.7
83 16.3 20.9 24.2 24.3 17.8 22.7 24.9 25.0 19.3 24.6 25.5 25.7 20.9 26.6 26.0 26.2 22.5 28.5 26.5 26.7
80 14.2 18.7 22.0 22.2 15.3 20.2 23.8 23.9 16.4 21.7 25.5 25.7 17.6 23.3 26.0 26.2 18.8 24.8 26.5 26.7
77 12.0 16.6 19.9 20.1 12.8 17.7 21.3 21.4 13.5 18.8 22.6 22.8 14.3 19.9 22.7 22.9 15.1 21.1 22.8 22.9
74 9.9 14.5 17.8 17.9 10.2 15.2 18.7 18.9 10.6 15.9 19.7 19.9 11.0 16.6 19.4 19.5 11.3 17.4 19.0 19.2
71 - 12.3 15.6 15.8 - 12.6 16.2 16.4 - 12.9 16.8 17.0 - 13.3 16.1 16.2 - 13.6 15.3 15.5
68 - 10.2 13.5 13.6 - 10.1 13.7 13.8 - 10.0 13.9 14.0 - 10.0 12.7 12.9 - 9.9 11.6 11.8
105 °F
Net Cap
MBH
28.5 24.8 22.5 22.6 29.1 25.3 23.0 23.0 29.7 25.9 23.5 23.5 30.3 26.4 23.9 24.0 30.8 26.9 24.4 24.4
Total Power
Input kW
3.31 3.17 3.08 3.10 3.40 3.25 3.16 3.17 3.48 3.33 3.23 3.25 3.54 3.39 3.29 3.31 3.60 3.44 3.35 3.36
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 17.6 21.9 22.5 22.6 19.5 23.6 23.0 23.0 21.5 25.3 23.5 23.5 23.5 26.1 23.9 24.0 25.5 26.9 24.4 24.4
83 15.5 19.8 22.2 22.3 17.0 21.7 22.8 22.9 18.5 23.5 23.5 23.5 20.1 24.9 23.9 24.0 21.7 26.3 24.4 24.4
80 13.4 17.6 20.1 20.1 14.5 19.1 21.8 21.8 15.6 20.6 23.5 23.5 16.8 22.2 23.9 24.0 18.0 23.8 24.4 24.4
77 11.2 15.5 17.9 18.0 12.0 16.6 19.2 19.3 12.7 17.7 20.6 20.6 13.5 18.9 20.6 20.6 14.3 20.0 20.6 20.7
74 9.1 13.4 15.8 15.8 9.4 14.1 16.7 16.8 9.8 14.8 17.6 17.7 10.2 15.6 17.3 17.3 10.6 16.3 16.9 17.0
71 - 11.2 13.7 13.7 - 11.6 14.2 14.2 - 11.9 14.7 14.8 - 12.2 14.0 14.0 - 12.6 13.2 13.2
68 - 9.1 11.5 11.6 - 9.0 11.7 11.7 - 9.0 11.8 11.9 - 8.9 10.6 10.7 - 8.9 9.5 9.5
115 °F
Net Cap
MBH
26.1 22.4 20.7 20.6 26.5 22.7 21.1 21.0 27.0 23.1 21.4 21.3 27.5 23.6 21.8 21.8 28.0 24.0 22.2 22.2
Total Power
Input kW
3.49 3.32 3.24 3.25 3.57 3.40 3.32 3.33 3.66 3.48 3.40 3.41 3.71 3.54 3.45 3.46 3.77 3.59 3.50 3.51
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 16.8 20.8 20.7 20.6 18.7 22.0 21.1 21.0 20.7 23.1 21.4 21.3 22.7 23.6 21.8 21.8 24.7 24.0 22.2 22.2
83 14.7 18.7 20.2 20.2 16.2 20.6 20.8 20.8 17.8 22.5 21.4 21.3 19.4 23.2 21.8 21.8 20.9 24.0 22.2 22.2
80 12.5 16.5 18.1 18.0 13.7 18.1 19.8 19.7 14.8 19.6 21.4 21.3 16.0 21.1 21.8 21.8 17.2 22.7 22.2 22.2
77 10.4 14.4 16.0 15.9 11.2 15.5 17.2 17.2 11.9 16.7 18.5 18.4 12.7 17.8 18.5 18.4 13.5 19.0 18.5 18.4
74 8.3 12.3 13.8 13.8 8.6 13.0 14.7 14.6 9.0 13.7 15.6 15.5 9.4 14.5 15.2 15.1 9.8 15.3 14.8 14.7
71 - 10.1 11.7 11.6 - 10.5 12.2 12.1 - 10.8 12.7 12.6 - 11.2 11.9 11.8 - 11.5 11.1 11.0
68 - 8.0 9.6 9.5 - 7.9 9.6 9.6 - 7.9 9.7 9.7 - 7.9 8.5 8.5 - 7.8 7.3 7.3
125 °F
Net Cap
MBH
23.7 19.9 18.9 18.7 24.0 20.1 19.1 18.9 24.2 20.4 19.4 19.2 24.7 20.8 19.7 19.5 25.2 21.2 20.1 19.9
Total Power
Input kW
3.7 3.5 3.4 3.4 3.8 3.6 3.5 3.5 3.8 3.6 3.6 3.6 3.9 3.7 3.6 3.6 3.9 3.7 3.7 3.7
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 16.0 19.7 18.9 18.7 17.9 20.3 19.1 18.9 19.9 20.9 19.4 19.2 21.9 21.1 19.7 19.5 23.9 21.2 20.1 19.9
83 13.9 17.6 18.3 18.1 15.4 19.5 18.8 18.6 17.0 21.4 19.4 19.2 18.6 21.6 19.7 19.5 20.2 21.7 20.1 19.9
80 11.7 15.5 16.1 16.0 12.9 17.0 17.7 17.6 14.0 18.5 19.4 19.2 15.2 20.1 19.7 19.5 16.4 21.7 20.1 19.9
77 9.6 13.3 14.0 13.8 10.4 14.5 15.2 15.0 11.1 15.6 16.4 16.2 11.9 16.8 16.4 16.2 12.7 17.9 16.4 16.2
74 7.5 11.2 11.9 11.7 7.8 11.9 12.7 12.5 8.2 12.7 13.5 13.3 8.6 13.4 13.1 12.9 9.0 14.2 12.6 12.4
71 - 9.0 9.7 9.6 - 9.4 10.2 10.0 - 9.8 10.6 10.4 - 10.1 9.8 9.6 - 10.5 8.9 8.7
68 - 6.9 7.6 7.4 - 6.9 7.6 7.5 - 6.8 7.7 7.5 - 6.8 6.4 6.2 - 6.8 5.2 5.0
1
= These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
