COOLING CAPACITIES - 3 TON (BHA036)
Temperature of Air on
Outdoor Coil
Air On Indoor Coil
900 CFM 1,050 CFM 1,200 CFM 1,350 CFM 1,500 CFM
WB°FWB°FWB°FWB°FWB°F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
37.1 33.9 30.2 29.4 39.8 36.4 32.4 31.5 42.5 38.9 34.6 33.7 44.4 40.6 36.1 35.2 46.3 42.3 37.7 36.6
Total Power
Input kW
3.62 3.49 3.41 3.40 3.67 3.54 3.46 3.45 3.72 3.59 3.51 3.49 3.78 3.65 3.57 3.55 3.84 3.71 3.62 3.61
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 22.5 28.4 30.2 29.4 25.3 31.9 32.4 31.5 28.2 35.4 34.6 33.7 30.7 38.5 36.1 35.2 33.3 41.5 37.7 36.6
83 19.9 25.8 30.2 29.4 22.3 28.9 32.4 31.5 24.7 31.9 34.6 33.7 26.8 34.5 36.1 35.2 28.8 37.1 37.7 36.6
80 17.3 23.2 27.6 27.5 19.3 25.8 30.7 30.6 21.2 28.4 33.8 33.7 22.8 30.5 35.7 35.2 24.3 32.6 37.7 36.6
77 14.8 20.7 25.0 25.0 16.2 22.8 27.7 27.6 17.7 24.9 30.3 30.2 18.8 26.5 31.7 31.2 19.9 28.1 33.2 32.2
74 12.2 18.1 22.5 22.4 13.2 19.8 24.6 24.5 14.2 21.4 26.8 26.7 14.8 22.6 27.8 27.2 15.4 23.7 28.7 27.7
71 - 15.5 19.9 19.8 - 16.7 21.6 21.5 - 17.9 23.3 23.2 - 18.6 23.8 23.2 - 19.2 24.3 23.2
68 - 13.0 17.3 17.3 - 13.7 18.6 18.5 - 14.4 19.8 19.7 - 14.6 19.8 19.2 - 14.7 19.8 18.8
95 °F
Net Cap
MBH
36.3 31.3 27.5 26.9 38.8 33.5 29.4 28.8 41.4 35.7 31.4 30.7 43.1 37.2 32.7 32.0 44.9 38.7 34.1 33.3
Total Power
Input kW
3.84 3.70 3.62 3.62 3.88 3.75 3.67 3.66 3.93 3.80 3.71 3.71 4.00 3.86 3.77 3.77 4.06 3.92 3.83 3.83
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 22.6 27.1 27.5 26.9 25.5 30.5 29.4 28.8 28.4 34.0 31.4 30.7 31.2 36.3 32.7 32.0 34.0 38.7 34.1 33.3
83 20.0 24.5 27.5 26.9 22.5 27.5 29.4 28.8 24.9 30.5 31.4 30.7 27.2 33.3 32.7 32.0 29.5 36.0 34.1 33.3
80 17.4 22.0 25.5 25.0 19.4 24.5 28.4 27.8 21.4 27.0 31.4 30.7 23.2 29.3 32.7 32.0 25.1 31.6 34.1 33.3
77 14.9 19.4 23.0 22.4 16.4 21.4 25.4 24.8 17.9 23.5 27.9 27.2 19.3 25.3 28.7 28.0 20.6 27.1 29.6 28.8
74 12.3 16.8 20.4 19.9 13.4 18.4 22.4 21.8 14.4 20.0 24.4 23.7 15.3 21.3 24.7 24.0 16.1 22.6 25.1 24.4
71 - 14.3 17.8 17.3 - 15.4 19.4 18.7 - 16.5 20.9 20.2 - 17.3 20.7 20.0 - 18.2 20.6 19.9
68 - 11.7 15.3 14.7 - 12.3 16.3 15.7 - 13.0 17.4 16.7 - 13.3 16.8 16.1 - 13.7 16.2 15.4
105 °F
Net Cap
MBH
32.4 27.9 25.1 23.7 34.8 29.9 27.0 25.5 37.1 32.0 28.8 27.2 38.7 33.3 30.0 28.3 40.2 34.6 31.2 29.5
Total Power
Input kW
4.06 3.90 3.85 3.84 4.10 3.95 3.89 3.89 4.15 3.99 3.94 3.93 4.22 4.06 4.00 4.00 4.29 4.13 4.07 4.07
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 21.0 25.8 25.1 23.7 23.9 28.4 27.0 25.5 26.9 31.1 28.8 27.2 29.5 32.9 30.0 28.3 32.1 34.6 31.2 29.5
83 18.5 23.2 25.1 23.7 20.9 26.2 27.0 25.5 23.4 29.3 28.8 27.2 25.5 31.3 30.0 28.3 27.6 33.3 31.2 29.5
80 15.9 20.6 23.1 21.8 17.9 23.2 26.0 24.5 19.9 25.8 28.8 27.2 21.5 27.9 30.0 28.3 23.2 30.1 31.2 29.5
77 13.3 18.1 20.5 19.2 14.8 20.2 22.9 21.5 16.4 22.3 25.3 23.7 17.5 24.0 26.0 24.3 18.7 25.6 26.7 25.0
74 10.8 15.5 18.0 16.7 11.8 17.2 19.9 18.4 12.9 18.8 21.8 20.2 13.5 20.0 22.0 20.4 14.2 21.2 22.3 20.5
71 - 12.9 15.4 14.1 - 14.1 16.9 15.4 - 15.3 18.3 16.7 - 16.0 18.1 16.4 - 16.7 17.8 16.0
68 - 10.4 12.8 11.5 - 11.1 13.8 12.4 - 11.8 14.8 13.2 - 12.0 14.1 12.4 - 12.2 13.3 11.6
115 °F
Net Cap
MBH
28.5 24.5 22.8 20.5 30.7 26.4 24.5 22.1 32.9 28.3 26.3 23.7 34.3 29.4 27.3 24.7 35.6 30.5 28.4 25.6
Total Power
Input kW
4.27 4.10 4.07 4.07 4.32 4.14 4.12 4.12 4.37 4.19 4.16 4.16 4.44 4.26 4.23 4.23 4.52 4.33 4.30 4.30
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 19.5 24.5 22.8 20.5 22.4 26.4 24.5 22.1 25.3 28.3 26.3 23.7 27.8 29.4 27.3 24.7 30.2 30.5 28.4 25.6
83 16.9 21.9 22.8 20.5 19.4 25.0 24.5 22.1 21.8 28.1 26.3 23.7 23.8 29.3 27.3 24.7 25.7 30.5 28.4 25.6
80 14.4 19.3 20.6 18.6 16.3 22.0 23.5 21.2 18.3 24.6 26.3 23.7 19.8 26.6 27.3 24.7 21.3 28.6 28.4 25.6
77 11.8 16.8 18.1 16.1 13.3 18.9 20.4 18.1 14.8 21.1 22.8 20.2 15.8 22.6 23.3 20.7 16.8 24.2 23.9 21.1
74 9.2 14.2 15.5 13.5 10.3 15.9 17.4 15.1 11.3 17.6 19.3 16.7 11.8 18.7 19.4 16.7 12.3 19.7 19.4 16.7
71 - 11.6 12.9 10.9 - 12.9 14.4 12.1 - 14.1 15.8 13.2 - 14.7 15.4 12.7 - 15.2 14.9 12.2
68 - 9.1 10.4 8.4 - 9.8 11.3 9.0 - 10.6 12.3 9.7 - 10.7 11.4 8.7 - 10.7 10.5 7.7
125 °F
Net Cap
MBH
24.7 21.1 20.4 17.4 26.7 22.8 22.1 18.8 28.7 24.5 23.7 20.2 29.8 25.5 24.6 21.0 30.9 26.4 25.5 21.7
Total Power
Input kW
4.5 4.3 4.3 4.3 4.5 4.3 4.3 4.3 4.6 4.4 4.4 4.4 4.7 4.5 4.5 4.5 4.7 4.5 4.5 4.5
Sensible Capacity
MBH
1
Entering Dry
Bulb,°F
86 18.0 23.2 20.4 17.4 20.8 24.3 22.1 18.8 23.7 25.4 23.7 20.2 26.0 25.9 24.6 21.0 28.3 26.4 25.5 21.7
83 15.4 20.6 20.4 17.4 17.8 23.8 22.1 18.8 20.2 26.9 23.7 20.2 22.0 27.3 24.6 21.0 23.8 27.7 25.5 21.7
80 12.8 18.0 18.2 15.5 14.8 20.7 21.0 17.8 16.7 23.4 23.7 20.2 18.0 25.3 24.6 21.0 19.4 27.2 25.5 21.7
77 10.3 15.5 15.6 12.9 11.7 17.7 17.9 14.8 13.2 19.9 20.2 16.7 14.1 21.3 20.6 17.0 14.9 22.7 21.0 17.3
74 7.7 12.9 13.1 10.3 8.7 14.7 14.9 11.8 9.7 16.4 16.7 13.2 10.1 17.3 16.7 13.0 10.4 18.2 16.6 12.8
71 - 10.3 10.5 7.8 - 11.6 11.9 8.8 - 12.9 13.2 9.7 - 13.3 12.7 9.0 - 13.8 12.1 8.3
68 - 7.8 7.9 5.2 - 8.6 8.8 5.7 - 9.4 9.7 6.2 - 9.4 8.7 5.0 - 9.3 7.6 3.9
1
= These capacities are net capacities - indoor fan heat deducted.
ALL SENSIBLE CAPACITY
