036-21004-002 Rev. B (0602)
Unitary Products Group 3
- = Not applicable
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT KW
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
+ TXV
3
EER
TOTAL SENS.
1 PH 14 SEER AC WITH N-AH / G2FD
FRCS0241BD N1AHB0806 2,5,8,10 17 G2FD036S17 800 25.2 18.1 - 14.00 12.35
FRCS0301BD N1AHB1206 5,8,10,15,19 17 G2FD036S17 1000 28.8 20.7 - 13.10 11.80
FRCS0361CD
N1AHB1206 5,8,10,15,19 17 G2FD036S17 1200 34.0 24.5 - 13.35 11.80
N1AHB1206 5,8,10,15,19 17 G2FD046S17 1200 35.0 25.6 - 14.00 12.20
N1AHD1406 5,8,10,15 24 G2FD048S24 1200 35.4 25.7 - 14.00 12.50
N1AHD1406 5,8,10,15 24 G2FD060S24 1200 36.0 26.1 - 14.20 12.80
FRCS0421CE
N1AHC1606 5,8,10,15,20 21 G2FD042S21 1400 39.0 28.2 - 13.25 11.35
N1AHC1606 5,8,10,15,20 21 G2FD048S21 1400 39.5 28.9 - 13.50 11.60
N1AHD1406 5,8,10,15 24 G2FD060S24 1400 40.5 29.6 - 14.00 12.00
FRCS0481CE
N1AHD2006 8,10,15,20,25,30 24 G2FD060S24 1600 46.5 33.9 - 13.85 11.80
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 1600 47.0 34.3 - 14.00 11.90
FRCS0601BF
N1AHD2006 8,10,15,20,25,30 24 G2FD060S24 1900 53.5 37.1 - 13.50 12.00
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 2050 54.5 39.1 - 13.50 12.10
1 PH 14 SEER AC / N1VS - VARIABLE SPEED
FRCS0241BD
N1VSB12 10,15,18 17 G2FD036S17 870 25.6 18.1 - 15.00 13.85
N1VSB12 10,15,18 17 G2FD046S17 870 26.2 18.9 - 15.50 14.15
FRCS0301BD
N1VSB12 10,15,18 17 G2FD036S17 1000 29.4 20.7 - 14.50 12.95
N1VSB12 10,15,18 17 G2FD046S17 1070 30.0 21.6 - 15.35 13.60
FRCS0361CD
N1VSB12 10,15,18 17 G2FD046S17 1250 35.2 25.6 - 14.00 12.40
N1VSC16 10,15,18 21 G2FD048S21 1285 36.0 25.7 - 15.00 13.60
FRCS0421CE
N1VSC16 10,15,18 21 G2FD048S21 1420 40.5 28.9 - 14.50 12.50
N1VSC16 10,15,18 21 G2FD048S21 1420 40.5 28.9 - 14.50 12.50
N1VSD20 10,15,18,30 24 G2FD060S24 1420 41.5 29.6 - 15.50 13.20
FRCS0481CE
N1VSC16 10,15,18 21 G2FD048S21 1590 46.0 33.2 - 14.30 12.20
N1VSD20 10,15,18,30 24 G2FD060S24 1600 47.0 33.9 - 14.65 12.40
FRCS0601BF
N1VSD20 8,10,15,20,25,30 24 G2FD060S24 1780 53.5 36.3 - 13.75 12.35
N1VSD20 8,10,15,20,25,30 24 G2FD061H24 1780 54.5 37.0 - 14.00 12.60
1 PH 14 SEER AC / F2RP / RC / FP / FC / FV
4,5
FRCS0241BD
F2RP/FP036 5,8,10,15,19 21 - 800 25.0 18.0 - 13.80 12.30
F2FP040 5,8,10,15 21 - 800 25.4 17.4 - 14.00 12.75
FRCS0301BD
F2RP/FP036 5,8,10,15,19 21 - 1000 29.8 21.5 - 13.85 12.40
F2FP045 5,8,10,15 24 - 1000 30.6 21.5 - 14.00 12.70
FRCS0361CD
F2RP/FP036 5,8,10,15,19 21 - 1200 34.4 24.8 - 13.50 12.10
F2RP/FP042 5,8,10,15 21 - 1200 34.4 24.8 - 13.30 11.90
F2FP045 5,8,10,15 24 - 1200 36.0 25.5 - 14.00 12.65
FRCS0421CE
F2FP045 5,8,10,15 24 - 1400 40.5 29.8 - 14.00 12.00
F2FP048 5,8,10,15,20,25 24 - 1400 39.5 28.9 - 13.25 11.30
FRCS0481CE
F2FP060 5,8,10,15,20,25 24 - 1600 46.0 33.4 - 13.00 11.25
F2FV060 8,10,15,20,25 24 - 1625 47.5 34.9 - 15.50 13.20
FRCS0601BF
F2FP060 10,15,20,25 24 -- 1900 53.0 36.7 - 13.00 11.60
F2FV060 10,15,20,25 24 -- 1900 53.5 36.3 - 13.75 12.35
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
KW includes compressor, outdoor fan and indoor blower motor watts. Add-on coils include 365 watts/1000 CFM for blower motor.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters.
3. TXV = Use 1TV700 Series Kit.
4. To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC
. models. All ratings remain the same.
5. FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D (Blower on Delay) standard.
