Service manual
6
Model
Y9USC-12 B5R
Y9USE-12 B5R
Factory Model
CE-KC35/E1N2
CE-KCR35/E1N2
Power supply
Ph-V-Hz
1Ph , 220-240V~, 50Hz
1Ph , 220-240V~, 50Hz
Capacity
Btu/h
12000
12000
Input
W
1420
1400
Rated current
A
6.3
6.2
Cooling
EER
Btu/w.h W/W
8.5,2.48
8.6,2.51
Capacity
Btu/h
12000
Input
W
1210
Rated current
A
5.4
Heating
COP
W/W
2.9
Moisture Removal
L/h
1.1
1.1
Max. input consumption
W
1760
1680
Max. current
A
9.1
8.5
Starting current
A
Plug type
Thermostat type
Mechanical control
Mechanical control
Model
PG225X2C-4FT
PG225X2C-4FT
Type
ROTARY
ROTARY
Brand
TOSHIBA
TOSHIBA
Capacity
Btu/h
13540
13540
Input
W
1290
1290
Rated current(RLA)
A
6
6
Locked rotor Amp(LRA)
A
Not Fixed
Not Fixed
Thermal protector
INTERNAL
INTERNAL
Capacitor
uF
35
35
Compressor
Refrigerant oil
ml
480
480
Refrigerant type
R407C/870g
R407C/900g
Design pressure
MPa
2.6
2.6
Model
YSK70-6C
YSK70-6C
Brand
Welling,Broad
Welling,Broad
Input
W
113/104/100
113/104/100
Capacitor
uF
2.5
2.5
Fan motor
Speed(hi/mi/lo)
r/min
900/800/700
900/800/700
a.Number of rows
3
3
b.Tube pitch(a)x row pitch(b)
mm
25.4X22
25.4X22
c.Fin spacing
mm
1.7
1.7
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
9.53x0.27, innergroove tube
9.53x0.27, innergroove tube
f.Coil length x height x width
mm
317X355.6X66
317X355.6X66
Evaporator
g.Number of circuits
2
2
Indoor air flow (Hi/Mi/Lo)
m3/h
550/500/450
550/500/450
Indoor noise level (Hi/Mi/Lo)
dB(A)
50/47/44
50/47/44
