York YCD42B23S User Manual

5752570-YTG-C-1020
114 Johnson Controls Ducted Systems
COIL MULTIPLIERS - 5 TON
Air Handler Coil T.C. S.C. kW
– CF/CM/CU60C 0.99 1.08 0.99
– CF/CM/CU60D 1.00 1.00 1.00
– CF/CM/CU60D 1.00 1.00 1.00
– CF/CM64D 1.02 1.12 1.02
AE60CX22 – 1.01 1.08 0.99
AE60DX21 – 1.03 1.08 1.00
AVC60DX21 – 1.02 1.08 1.00
ME16CN21 CF/CM60C 1.00 1.07 0.98
ME20DN21 CF/CM60D 1.01 1.09 0.99
ME20DN21 CF/CM64D 1.02 1.11 0.97
MVC16CN21 CF/CM60C 1.01 1.08 0.97
MVC20DN21 CF/CM60D 1.01 1.05 0.99
MVC20DN21 CF/CM64D 1.02 1.08 1.00
FURNACE MULTIPLIERS - 5 TON
Furnaces Coil T.C. S.C. kW
TL8E080C16UH11 CF/CM/CU60C 0.98 1.03 0.98
TL8E080C16UH11 CF/CM/CU60D 1.00 1.07 1.00
TL8E080C16UH11 CF/CM64D 1.01 1.07 1.01
TL8E100C20UH11 CF/CM/CU60C 0.99 1.05 0.99
TL8E100C20UH11 CF/CM/CU60D 1.01 1.08 1.01
TL8E100C20UH11 CF/CM64D 1.02 1.08 1.00
TL9E100C20UH11 CF/CM/CU60C 0.98 1.04 0.98
TL9E100C20UH11 CF/CM/CU60D 1.01 1.08 1.01
TL9E100C20UH11 CF/CM64D 1.02 1.08 1.00
TM8E080C16MP11 CF/CM/CU60C 0.98 1.04 0.98
TM8E080C16MP11 CF/CM/CU60D 0.98 1.04 0.98
TM8E080C16MP11 CF/CM64D 1.01 1.07 1.01
TM8E080C20MP11 CF/CM/CU60C 0.98 1.03 0.98
TM8E080C20MP11 CF/CM/CU60D 0.98 1.04 0.96
TM8E080C20MP11 CF/CM64D 1.02 1.08 1.00
TM8E100C16MP11 CF/CM/CU60C 0.98 1.04 0.98
TM8E100C16MP11 CF/CM/CU60D 0.98 1.04 0.98
TM8E100C16MP11 CF/CM64D 1.01 1.07 1.01
TM8E100C20MP11 CF/CM/CU60C 0.99 1.08 0.99
TM8E100C20MP11 CF/CM/CU60D 0.98 1.03 0.96
TM8E100C20MP11 CF/CM64D 1.01 1.05 0.99
TM8E120C16MP11 CF/CM/CU60C 0.98 1.05 0.98
TM8E120C16MP11 CF/CM/CU60D 0.98 1.04 0.98
TM8E120C16MP11 CF/CM64D 1.01 1.07 1.01
TM8E120C20MP11 CF/CM/CU60C 0.99 1.08 0.99
TM8E120C20MP11 CF/CM/CU60D 0.98 1.03 0.96
TM8E120C20MP11 CF/CM64D 1.01 1.05 0.99
TM8E130D20MP11 CF/CM/CU60D 0.99 1.07 0.99
TM8E130D20MP11 CF/CM64D 1.01 1.08 1.01
TM8V080C16MP11C CF/CM/CU60D 1.00 1.08 1.00
TM8V080C16MP12C CF/CM/CU60D 1.00 1.08 1.00
TM8V100C16MP11C CF/CM/CU60D 1.00 1.08 1.00
TM8V100C16MP12C CF/CM/CU60D 1.00 1.08 1.00
TM8V100C20MP11C CF/CM/CU60C 0.99 1.04 0.99
TM8V100C20MP11C CF/CM/CU60D 0.99 1.04 0.97
TM8V100C20MP11C CF/CM64D 0.99 1.05 0.97
TM8V100C20MP12C CF/CM/CU60C 0.99 1.04 0.99
TM8V100C20MP12C CF/CM/CU60D 0.99 1.04 0.97
TM8V100C20MP12C CF/CM64D 0.99 1.05 0.97
TM8V120C20MP11C CF/CM/CU60C 0.99 1.04 0.99
TM8V120C20MP11C CF/CM/CU60D 0.99 1.04 0.97
TM8V120C20MP11C CF/CM64D 0.99 1.05 0.97
TM8V120C20MP12C CF/CM/CU60C 0.99 1.04 0.99
TM8V120C20MP12C CF/CM/CU60D 0.99 1.04 0.97
TM8V120C20MP12C CF/CM64D 0.99 1.05 0.97
TM8X080C16MP11 CF/CM/CU60C 0.99 1.04 0.99
TM8X080C16MP11 CF/CM/CU60D 1.00 1.05 0.98
TM8X080C16MP11 CF/CM64D 0.98 1.03 0.98
TM8X100C16MP11 CF/CM/CU60C 0.99 1.04 0.99
TM8X100C16MP11 CF/CM/CU60D 1.00 1.05 0.98
TM8X100C16MP11 CF/CM64D 0.98 1.03 0.98
TM8X100C20MP11 CF/CM/CU60C 0.98 1.03 0.96
TM8X100C20MP11 CF/CM/CU60D 0.99 1.05 0.97
TM8X100C20MP11 CF/CM64D 0.99 1.05 0.97
TM8X120C20MP11 CF/CM/CU60C 0.98 1.03 0.96
TM8X120C20MP11 CF/CM/CU60D 0.99 1.05 0.97
TM8X120C20MP11 CF/CM64D 0.99 1.05 0.97
TM8Y080C16MP11 CF/CM/CU60C 0.99 1.04 0.99
TM8Y080C16MP11 CF/CM/CU60D 1.00 1.05 0.98
TM8Y080C16MP11 CF/CM64D 0.98 1.03 0.98
TM8Y100C16MP11 CF/CM/CU60C 0.99 1.04 0.99
TM8Y100C16MP11 CF/CM/CU60D 1.00 1.05 0.98
TM8Y100C16MP11 CF/CM64D 0.98 1.03 0.98
TM8Y100C20MP11 CF/CM/CU60C 0.98 1.03 0.96
TM8Y100C20MP11 CF/CM/CU60D 0.99 1.05 0.97
TM8Y100C20MP11 CF/CM64D 0.99 1.05 0.97
TM8Y120C20MP11 CF/CM/CU60C 0.98 1.03 0.96
TM8Y120C20MP11 CF/CM/CU60D 0.99 1.05 0.97
TM8Y120C20MP11 CF/CM64D 0.99 1.05 0.97
TM9E080C20MP12 CF/CM/CU60C 0.99 1.08 0.99
TM9E080C20MP12 CF/CM/CU60D 0.98 1.03 0.96
TM9E080C20MP12 CF/CM64D 1.01 1.11 0.99
TM9E100C16MP12 CF/CM/CU60D 0.98 1.05 0.98
TM9E100C20MP11 CF/CM/CU60C 0.96 1.01 0.96
TM9E100C20MP11 CF/CM/CU60D 0.97 1.03 0.95
TM9E100C20MP11 CF/CM64D 0.99 1.04 0.99
TM9E100C20MP12 CF/CM/CU60C 0.99 1.08 0.99
TM9E100C20MP12 CF/CM/CU60D 0.98 1.03 0.96
TM9E100C20MP12 CF/CM64D 1.01 1.05 0.99
TM9E120D20MP11 CF/CM/CU60D 0.99 1.05 0.97
TM9E120D20MP11 CF/CM64D 1.00 1.07 0.98
TM9E120D20MP12 CF/CM/CU60D 0.99 1.07 0.99
TM9E120D20MP12 CF/CM64D 1.01 1.08 0.99
TM9V080C16MP11C CF/CM/CU60D 0.97 1.01 0.97
TM9V080C16MP12C CF/CM/CU60D 0.97 1.01 0.97
TM9V100C16MP11C CF/CM/CU60C 1.00 1.07 1.00
TM9V100C16MP11C CF/CM/CU60D 0.98 1.04 0.98
TM9V100C16MP11C CF/CM64D 1.00 1.07 1.00
TM9V100C16MP12C CF/CM/CU60C 1.00 1.07 1.00
TM9V100C16MP12C CF/CM/CU60D 0.98 1.04 0.98
TM9V100C16MP12C CF/CM64D 1.00 1.07 1.00
TM9V100C20MP11C CF/CM/CU60C 0.98 1.05 0.98
TM9V100C20MP11C CF/CM/CU60D 0.98 1.05 0.98
FURNACE MULTIPLIERS - 5 TON (Continued)
Furnaces Coil T.C. S.C. kW

York YCD42B23S Specifications

General

Model Number	YCD42B23S
Category	Air Conditioner
Cooling Capacity	42000 BTU/h
Refrigerant	R410A
Power Supply	220-240V, 50Hz, 1Ph
