FIGURE 34 - FAN CONTACTORS AND 3T TRANSFORMER, 2 COMPRESSOR
COMPONENT LOCATIONS (CONT'D)
LD10584
FAN CONTACTORS
4CR-9CR
3T TRANSFORMER
(24VAC to SCR Gate Driver Board and VSD Logic Board)
