COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL W
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
13 SEER HP WITH MA
YHJD18S41S1
MA08B 17 FC/MC/PC18B 600 17.0 12.6 13.00 11.00
MA08B 17 FC/MC/PC24B 600 17.0 12.9 13.50 11.00
YHJD24S41S1 MA08B 17 FC/MC/PC35B 800 23.0 17.5 13.00 11.00
YHJD30S41S1 MA12B 17 FC/MC/PC43B 1000 29.0 23.4 13.00 11.00
YHJD36S41S1
MA12B 17 FC/MC/PC43B 1200 35.0 26.8 13.00 11.00
MA14D 24 FC/MC/PC48D 1200 35.0 27.0 13.00 11.00
YHJD42S41S1
MA14D 24 FC/MC/PC48D 1400 41.5 31.4 13.00 11.00
MA16C 21 FC/MC/PC48C 1400 41.5 31.4 13.00 11.00
MA14D 24 FC/MC/PC60D 1400 41.0 31.2 13.00 11.00
MA16C 21 FC/MC/PC60C 1400 41.0 31.2 13.00 11.00
YHJD48S41S1
MA16C 21 FC/MC/PC60C 1600 47.0 35.6 13.00 11.00
MA20D 24 FC/MC/PC60D 1600 47.0 35.6 13.00 11.00
MA20D 24 MC62D 1600 47.0 35.6 13.00 11.00
YHJD60S41S1 MA20D 24 MC62D 1800 54.0 42.5 13.00 11.00
13 SEER HP WITH MV - VARIABLE SPEED
YHJD18S41S1
MV12B 17 FC/MC/PC18B 600 17.0 12.9 14.00 12.00
MV12B 17 FC/MC/PC24B 600 17.0 13.2 14.00 12.00
YHJD24S41S1
MV12B 17 FC/MC/PC35B 800 23.0 17.9 14.00 12.00
MV16C 21 FC/MC/PC35C 800 23.0 17.9 14.00 12.00
YHJD30S41S1
MV16C 21 FC/MC/PC35C 1000 29.0 23.6 14.00 12.00
MV12B 17 FC/MC/PC43B 1000 29.0 23.8 14.00 12.00
MV16C 21 FC/MC/PC43C 1000 29.0 24.0 14.00 12.00
YHJD36S41S1
MV12B 17 FC/MC/PC43B 1200 35.0 27.0 13.50 11.50
MV16C 21 FC/MC/PC43C 1200 35.0 27.2 13.50 11.50
MV12D 24 FC/MC/PC48D 1150 35.0 26.8 13.50 11.50
MV16C 21 FC/MC/PC48C 1200 35.0 27.4 13.50 11.50
MV20D 24 FC/MC/PC48D 1200 35.0 27.4 13.50 11.50
YHJD42S41S1
MV16C 21 FC/MC/PC48C 1400 42.0 31.8 14.00 12.00
MV20D 24 FC/MC/PC48D 1400 42.0 32.0 14.00 12.00
MV20D 24 FC/MC/PC60D 1400 41.5 31.8 14.00 12.00
YHJD48S41S1
MV20D 24 FC/MC/PC60D 1600 47.5 36.0 14.00 11.80
MV20D 24 MC62D 1600 47.5 36.0 14.00 12.00
YHJD60S41S1 MV20D 24 MC62D 1800 54.5 43.0 13.50 11.60
13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
YHJD18S41S1 AV*24 17 – 550 17.0 13.0 14.00 12.00
YHJD24S41S1 AV*36 21 – 725 24.0 17.8 14.50 12.50
YHJD30S41S1 AV*36 21 – 1000 29.0 24.4 14.00 12.00
YHJD36S41S1 AV*36 21 – 1190 35.0 28.2 14.00 12.00
YHJD42S41S1 AV/SV*48 24 – 1385 41.5 31.8 14.25 12.00
YHJD48S41S1
AV/SV*48 24 – 1600 47.5 36.2 14.00 11.80
AV/SV*60 24 – 1560 47.5 35.0 14.50 12.00
F4FV060 24 – 1600 47.5 36.2 14.00 11.80
For Notes See Page 5.
