YORKVILLE AP6020 - Assembly Notes and Component Details

+55V
-55V
PCBPCB
TORQUE 4 INCH/LBTORQUE 4 INCH/LB
Z217 CLAMPZ217 CLAMP
Z217 CLAMPZ217 CLAMP
HEATSPREADER
#8701 4-40 KEPS NUT
#8485 SPLIT WASHER
PCB
PCB
#4124 THERMO PAD
HEATSPREADER
T126 TYPE DEVICE
V9.00
X8002
TB4
TB7
TB6 BLU
TB2
TB3
RED
GRY
V9.00
X8002
-145V
+145V
V9.00
X8002
PCBPCB
HEATSPREADERHEATSPREADER
T264 DEVICET264 DEVICE
#3846 MICA
TORQUE 4 INCH/LB
Z217 CLAMP
AP6020 / AM4CE / V62
FOR AP6020 (M1176A):
TB5 BRN
#8663 SPACER
AP6020 / AM4CE / V62
FOR AM4CE (M1370A):
AP6020 / AM4CE / V62
FOR V62 (M1178A):
HEATSPREADERHEATSPREADER
T126 TYPE DEVICET126 TYPE DEVICE
#8485 ZINC #6 WASHER#8485 ZINC #6 WASHER
#8701 4-40 KEPS NUT
OUTPUT +
OUTPUT -
14AWG
T-220 DEVICE
14AWG
14AWG
#3501 BELL WASHER
8. TAB WIRE COLOURS
#8741 4-40X 1/2" BOLT
#8871 4-40X 5/8" BOLT
TO-3 TRANSISTOR
#8761 BOLT
#3517 #8 NYLON WASHER#3517 #8 NYLON WASHER
#8701 4-40 KEPS NUT#8701 4-40 KEPS NUT
#8902 - 4-40 X 3/4 PAN PHIL#8902 - 4-40 X 3/4 PAN PHIL
#8820 WASHERS
PRODUCTION NOTES
14AWG
#8760 6-32 KEPS NUT
MICA GREASE IS REQUIRED ON
BOTH SIDES OF THE MICA PAD
HEATSPREADER
#3915 THERMAL PAD
#3851 1/2 PCB PLASTIC SPACER#3851 1/2 PCB PLASTIC SPACER
3. MOUNTING HARDWARE FOR Q23B AND Q24B.3. MOUNTING HARDWARE FOR Q23B AND Q24B.
7. NOTE THAT R146B AND R149B ARE 0R15.
5. MOUNTING HARDWARE FOR Q32A, Q32B
Q33A ANDQ33B
COOLED FROM WAVE SOLDER IS 6 INCH/LB
#3797 THERMO PAD#3797 THERMO PAD
INITIAL TORQUE FOR TO-3'S IS 8 INCH/LB
FINAL TORQUE AFTER HEATSINK HAS
#4060 SIL THERMO PAD#4060 SIL THERMO PAD
9. INDICATING THE TARGET MODEL
INVALID PRODUCT MODELS MUST BE CROSSED OUT IN THE PCB TITLE BOX.
FOR EXAMPLE, IF THE PCB IS STUFFED FOR THE AP6020, THEN MODELS 'AM4CE'
AND 'V62' MUST BE CROSSED OUT WITH A BLACK MARKER.
#8667 SHOULDER WASHER
TORQUE 4 INCH/LB
2. MOUNTING HARDWARE FOR Q25B AND Q26B.2. MOUNTING HARDWARE FOR Q25B AND Q26B.
1. MOUNTING DETAILS FOR 5W ADD #8629 SPACERS ONLY ON
5 WATT RESISTORS R130A, R130B AND R131B.
4. MOUNTING HARDWARE FOR Q17B AND Q18B.
SEE LAYOUT DIAGRAM
6. MOUNTING HARDWARE FOR TO3 OUTPUTS
M1370/M1370A/M1176/M1176A/ M1178/M1178A
#8902
440- SCREW
#3851
SPCR
#8485
WASHER
#4060
SIL-PAD
#3517
WASHER
Z217
CLAMP
FLIPPED VERSION
CLAMP DETAIL - SEE NOTES 2 AND 3.
CLAMP DETAIL FOR NOTE 4.
