YORKVILLE AP6020 - Product Specifications and Overview; Technical Specifications Table

Specifications
Amplifier class
H
Coninuous Average Power @ 8 ohms BCD (watts)
800 (x2)
Coninuous Average Power @ 4 ohms BCD (watts)
1300 (x2)
Coninuous Average Power @ 2 ohms BCD (watts)
2000 (x2)
Continuous Average Power Bridged BCD (watts)
4000 @ 4 ohms
Burst Average Power @ 8 ohms BCD (watts)
1200 (x2)
Burst Average Power @ 4 ohms BCD (watts)
2175 (x2)
Burst Average Power @ 2 ohms BCD (watts)
3625 (x2)
Burst Average Power Bridged BCD (watts)
7200 @ 4 ohms
Frequency Response (Hz, +/- 1dB)
20-20,000
Hum and Noise (un / Aweighted -dB)
0.971698113
THD -1kHz- 4 ohms
0.0001
THD - 20Hz-20kHz, 4 ohms
less than 0.1%
Slew Rate (V/uS)
25
Slew Rate Bridged (V/uS)
50
Damping Factor (30 Hz - 400 Hz @ 8 ohms)
600
Crosstalk (1kHz / 20Hz-20kHz)
-75 / -60 dB
Input Impedance - Bal/Unbal (ohms)
20,000/10,000
Input Sensitivity (Vrms) For Full Power Out
1.4 V
Max Voltage Gain (dB)
39
CMRR @ 60Hz (min/typ)
48/56 dB
Stereo / Mono / Bridge (S/M/B)
S/M/B
Protection
DC,Load,Thermal
Limiter
Peak
High Pass Filter
40Hz, 12dB Octave
Cooling
Dual Internal Fans
Cooling Path
Front to Rear
Fan Filter
2x User Serviceable
Inputs - XLR
2
Inputs - 1/4 inch Jacks
2
Outputs - Speakon 4-pin
2
Outputs - Binding Post
2
Power Consumption (typ/max)
1800/3000 watts
Rack Spaces
3
Transformer Type
Toroidal
Exterior Finish
Baked, Black Painted
Dimensions (DWH /D fm ears, inches)
18.75 x 19 x 5.25 x 17.75
Dimensions (DWH /D fm ears, cm)
47.6 x 18.3 x 13.3 x 45.1
Weight (lbs / kg)
67.9 / 30.8
