note: each enclosure can be adjusted ±6dB individually
ONE MICROPHONE, MULTIPLE NX55Ps
TO MIC IN
USE LINK USE LINKUSE LINK
TO MORE NX55Ps
TO MORE NX55Ps
USE LINK
USE LINK
*Use MIXER on
First nx55p ONLY!
config-01e-nx55p-1v0.eps
note: Turn MIXER option OFF on nx55p's
STEREO P.A., with EXTERNAL MIXER
TO LINK
TO LINK
MIXER OUTPUT
MIXER OUTPUT
config-02e-nx55ps-1v0.eps
