YORKVILLE NX55P - Page 14

12
P
550 WATT POWERED LOUDSPEAKER ENCLOSURE
NOTES:
ALL LINK CONNECTIONS FUNCTION AS
INPUTS OR OUTPUTS.
EXTERNAL MIXERS CONNECT TO LINK INPUTS
LINK
Yorkville
1
3
2
1
3
2
2
3
1
+24 PHANTOM
MIC
LINE / CD LEVEL
MIC LEVEL
LINE / CD
MIXER ON / OFF
NX55P LEVEL
