Stabilisers
Attach one stabiliser to each corner of tower at approx. 45
degrees. The bottom clamp should be fitted as low as
possible, refer to the diagram below. Ensure that all 4
rubber feet are in contact with the ground and that the
clamps are secured.
Position stabilisers as shown in diagrams.
When using the medium stabilisers, always extend the
telescopic legs to their maximum position and lock into
position with the interlock clip.
When moving tower lock each telescopic leg just clear of
the ground, unlock castors ensuring area is firm and clear
of all obstructions both on the ground and above. After
moving check all castors are firmly on the ground and
locked, and that the tower is vertical. Re-position stabilis-
ers as above.
Small Stabiliser
Medium Stabiliser
18
2.3m
4.6m
4.2m
2.9m
3.2m
1.3m
Bottom
clamp
For further information about
this product or any other
products and services,
please contact :
Youngman Group Ltd
The Causeway, Maldon,
Essex, CM9 4LJ,
United Kingdom
t +44 (0)1621 745900
f +44 (0)1621 859845
e sales@youngmangroup.com
youngmangroup.com
