PARTS LIST
YS PERFORMANCE
1295-C Industrial Court Gardnerville, NV89410
Phone: 775-782-4562
21
22
5
38
26
16
25
40
25
40
24
4
1
3
2
0
41
10
15
14
18
6
33
13
35
23
29
39
36
31
27
2
11
19
30
27
34
32
12

6
28
Specifications may be changed without pror notice. 2000/F
YY
YY
SS
SS
44
44
55
55
FF
FF
SS
SS
#PART# DESCRIPTION QTY
1 YS0110-45FS BackPlateGasket 1
2 YS0115-45FS ThrottleBody 1
3 YS0120-FS BackPlate 1
4 YS0125-45FS Crankshaft 1
5 YS0130-45FS WristPin 1
6 YS0135-45FS ThrotleGasket 1
7 YS0140-45FS MixtureControl(notPIctured) 1
8 YS0145-45FS GasketSet(AllGasket) 1
9 YS0150-45FS ThrottleSet(CompleteCarburetor) 1
10 YS0155-45FS Crankcase 1
11 YS0160-45FS ThrottleBarrel 1
12 YS0165-45FS NeedleSocket 1
13 YS0170-45FS RegulatorBody 1
14 YS0175-45FS RegulatorPlunger 1
15 YS0180-45FS PlungerSpring 1
16 YS0185-45FS CylinderHeadScrews 1
17 YS0190-45FS NeedleValveSet 1
18 YS0195-45FS RegulatorAdjustmentScrew 1
19 YS0200-45FS ThrottleArm/ScrewSet 1
20 YS0205-45FS BackPlateScrews 6
21 YS0210-45FS CylinderHead 1
22 YS0215-45FS CylinderHeadGasket 1
23 YS0220-45FS ThrottleRegMountingCcrews 1
24 YS0225-45FS RearBallBearing 1
25 YS0230-45FS Liner/PistonSetSideExhaust
26 YS0235-45FS ConRod 1
27 YS0380-45FS ThrottleBarrelRetainerScrew 1
28 YS0385-45FS NeedleValveDetentSpring 1
29 YS0390-45FS DriveWasherSet 1
30 YS0395-45FS ThrottleStopScrew/SpringSet
31 YS0400-45FS PropNut 1
32 YS0405-45FS CheckValve 1
33 YS0410-45FS Diaphragm 1
34 YS0415-45FS NeedleValve 1
35 YS0420-45FS FuelNipples/WashersSet 1
36 YS0425-45FS PropWasher 1
37 YS0430-45FS ORingSet
38 YS0435-45FS WristPinRetainer 1
39 YS0440-45FS FrontBallBearing 1
YY
YY
SS
SS
44
44
55
55
FF
FF
RR
RR
40 YS0100-45FR Liner/PistonSetRearExhaust 1
41 YS0105-45FR Crankcase 1
