1 F5101 Crankcase 1
F5102A Cylinder Head Assembly
2 F5102 Cylinder Head & Liner 1
3 F5103 Intake Valve 1
4 F5104 Exhaust Valve 1
5 F5105 Valve Spring Set 2
6 F9106 Spring Retainer Set 2
7 F9107 Valve Spring Retainer Clips 4
8 F5108 Cylinder O-ring 1
10 F5110 Head Screws 4
11 F5111 Valve Cover 1
12 F5112 Valve Cover Gasket 1
13 F5113 Valve Cover Screws 2
14 F5114 Intake Pipe 1
15 F5115 Intake Pipe O-ring 2
16 F5116 Crankshaft 1
17 F5117 Rear Bearing 1
18 F5118 Front Bearing 1
19 F5119 Front Bearing Oil Seal 1
20 F5120 Drive Washer 1
21 F5121 Drive Washer Retainer 1
22 F5122 Propeller Washer 1
23 F5123 Propeller Nut Set 2
24 F5124 Piston 1
25 F5125 Piston Ring 1
26 F5126 Wrist Pin 1
27 F5127 Wrist Pin Retainer 2
28 F5128 Rocker Arm Set 2
29 F1213 Tappet Adjusting Screw Set 2
30 F1214 Tappet Adjusting Lock Nut 2
31 F5131 Rocker Arm Shaft 1
32 F5132 Rocker Arm Screw 1
33 F1217 E Ring Set 2
34 F5134 Cam Gear 1
35 F5135 Cam Gear Cover 1
36 F5136 Cam Gear Cover O-Ring 1
37 F1234 Cam Gear Screws 2
38 F5138 Cam Gear Bearing Set 2
39 F5139 Cam Followers Set 2
40 F5140 Push Rods 2
41 F5141 Push Rod Covers 2
42 F5142 Push Rod Cover O-Ring 4
43 F5143 Con Rod 1
F5144A Back Plate Assembly
44 F5144 Back Plate 1
45 F5145 Disc Valve 1
46 F5146 Disc Valve Pin 1
47 F1229 Disc Valve Set Screw 1
49 F5149 Back Plate Gasket 1
50 F5150 Back Plate Screws 2
F5151A Carburetor Assembly
51 F5151 Carburetor Body 1
52 F5152 Throttle Barrel 1
53 F5153 Throttle Barrel Seal 1
54 R6124 Thorottle Barrel Retainer 1
55 F1260S Throttle Arm Set 1
56 F1258 Throttle Stop Screw 1
57 F1259 Throttle Stop Spring 1
F5158S Needle Valve Assembly
58 F5158 Needle Valve 1
59 F1546 Needle Valve O-ring 1
60 F1555 Needle Soket 1
61 F1256 Needle Soket O-ring 2
62 F1557 Needle Valve Detent 1
63 F5163 Fuel Nipple 1
64 F5186 Low Speed Needle Valve 1
65 F5187 Low Speed Needle Valve O-Ring 1
66 F5164 Carburetor Gasket 1
67 F5165 Carburetor Screws 1
F5166A Regulator Assembly 4
68 F5166 Regulator Body
69 F1245 Regulator Adjusting Screw 1
70 F1246 Regulator Adjusting Screw O-ring 1
71 F5169 Diaphram 1
72 R6138 Regulator Plunger 1
73 F5171 Plunger Spring 1
74 F5172 Regulator Screw Set 2
F5173S Muffler Set
75 F5173A Muffler Assembly 1
76 F5174 Exhaust Pipe 1
77 F5175 Rock Nuts 2
F5180 Gasket Set 3
F5181 O-Ring Set 11
#
PART
#
DESCRIPTION
QTY
'987
4 CYCLE
SUPER
CHARGER
FZ
53
YAMADA MFG.CO.,LTD
67 Tsuchitori Inuyama Aichi 484-0917 JAPAN
WARRANTY
Strict quality control is implemented by our factory in all phases,
from parts manufactiring to final assembly.
If performance deteriorates or a part fails within one year of purchase
due to a manufacturing error,YS will repair or replace the engine at no
charge. Warranty will not cover normal wear.
Should the engine be modified, incorrectly assembled or abused,
there will be a normal charge for parts and labor. The use of four
cycle fuel due to low oil content will also void warranty.
