A
66
67
80
18
21
20
22
23
19
38
34
38
36
35
37
40
42
41
42
39
8
27
27
26
43
24
25
33
33
30
30
28
29
29
31
2
3
10
10
4
28
32
5
6
12
11
13
7
79
78
80
65
50
44
45
49
46
16
17
1
63
51
60
61
62
59
58
54
55
57
56
53
52
64
15
14
15
47
67
73
72
70
68
74
69
71
DETAIL
A
75
76
77
WARRANTY
Strict quality control is implemented by our factory in all phases,
from parts manufactiring to final assembly.
If performance deteriorates or a part fails within one year of purchase
due to a manufacturing error,YS will repair or replace the engine at no
charge. Warranty will not cover normal wear.
Should the engine be modified, incorrectly assembled or abused,
there will be a normal charge for parts and labor. The use of four
cycle fuel due to low oil content will also void warranty.
1 YS5000 Crankcase 1
YS5005 Cylinder head assy.
2 YS5010 Cylinder head & liner 1
3 YS2810 Intake valve 1
4 YS2815 Exhaust valve 1
5 YS2820 Valve spring set 2
6 YS2030 Spring retainer set 2
7 YS2040 Spring retainer clips 4
8 YS5015 Cylinder gasket 1
10 YS2840 Head screws 4
11 YS2845 Valve cover 1
12 YS2850 Valve cover gasket 1
13 YS2855 Valve cover screws 2
14 YS2860 Intake pipe 1
15 YS2865 Intake pipe O ring 2
16 YS4380 Crankshaft 1
17 YS2875 Rear bearing 1
18 YS2880 Front bearing 1
19 YS2885 Front bearing oil seal 1
20 YS2890 Drive washer 1
21 YS2895 Drive washer retainer 1
22 YS0825 Propeller washer 1
23 YS0830 Propeller nuts 2
24 YS5020 Piston 1
25 YS4390 Piston ring 1
26 YS4395 Wrist pin 1
27 YS2925 Wrist pin retainer 2
28 YS2930 Rocker arm set 2
29 YS0560 Tappet adjusting screws 2
30 YS0565 Tappet adjusting lock nuts 2
31 YS2935 Rocker arm shaft 1
32 YS2940 Rocker arm screw 1
33 YS0580 E ring set 2
34 YS2945 Cam gear 1
35 YS2950 Cam gear cover 1
36 YS2955 Cam gear cover O ring 1
37 YS4400 Cam gear screws 2
38 YS2960 Cam gear bearing set 2
39 YS2965 Cam follower set 2
40 YS2970 Push rods 2
41 YS2975 Push rod covers 2
42 YS2980 Push rod cover O ring set 4
43 YS2985 Con rod 1
YS4000 Back plate assy.
44 YS2990 Back plate 1
45 YS2995 Disc valve 1
46 YS3000 Disc valve pin 1
47 YS0640 Disc valve set screw 1
49 YS3005 Back plate gasket 1
50 YS3010 Back plate screws 2
YS5090 Carburetor assy.
51 YS3015 Carburetor body 1
52 YS3020 Throttle barrell 1
53 YS3025 Throttle barrell seal 1
54 YS1090 Throttle barrell retainer 1
55 YS0200 Throttle arm set 1
56 YS0785 Throttle stop screw 1
57 YS0790 Throttle stop spring 1
YS3090 Needle valve assy.
58 YS3030 Needle valve 1
59 YS2695 Needle valve O ring 1
60 YS2700 Needle socket 1
61 YS0775 Needle socket O ring set 2
62 YS2710 Needle valve detent 1
63 YS3035 Fuel nipple 1
64 YS4010 Low speed needle valve 1
65 YS4015 Low speed needle valve O ring 1
66 YS3040 Carburetor gasket 1
67 YS3045 Carburetor screws 4
YS5075 Regulator assy.
68 YS5025 Regulator adjusting screw 1
69 YS5030 Regulator adjusting screw O ring 1
70 YS5035 Plunger spring 1
71 YS5040 Plunger 1
72 YS5045 Regulator body A 1
73 YS5050 Diaphram 1
74 YS5055 Regulator body B 1
75 YS5060 Regulator bracket set 1
76 YS5065 Under cover set 1
77 YS5070 Under cover gasket 1
YS3095 Muffler set
78 YS3065 Muffler assy. 1
79 YS3070 Exhaust pipe 1
80 YS3075 Rock nuts 1
YS5080 Gasket set 4
YS5085 O ring set 11
NO. PART# DESCRIPTION QTY
04/03
YS PERFORMANCE
1295-C Industrial Court Gardnerville, NV89410
Phone: 775-782-4562 Fax: 775-783-8518
